Additional parameter data 315
31.08 External event 4 type List 0…1 - 1 = 1
31.09 External event 5 source Binary src --1 = 1
31.10 External event 5 type List 0…1 - 1 = 1
31.11 Fault reset selection Binary src --1 = 1
31.12 Autoreset selection PB 0000h…FFFFh - 1 = 1
31.13 Selectable fault Real 0000h…FFFFh - 1 = 1
31.14 Number of trials Real 0…5 - 1 = 1
31.15 Total trials time Real 1.0…600.0 s 10 = 1 s
31.16 Delay time Real 0.0…120.0 s 10 = 1 s
31.19 Motor phase loss List 0…1 - 1 = 1
31.21 Supply phase loss List 0…1 - 1 = 1
31.22 STO indication run/stop List 0…5 - 1 = 1
31.23 Wiring or earth fault List 0…1 - 1 = 1
31.24 Stall function List 0…2 - 1 = 1
31.25 Stall current limit Real 0.0…1600.0 % 10 = 1%
31.26 Stall speed limit Real 0.00…10000.00 rpm 100 = 1 rpm
31.27 Stall frequency limit Real 0.00…1000.00 Hz 100 = 1 Hz
31.28 Stall time Real 0…3600 s 1 = 1 s
31.30 Overspeed trip margin Real 0.00…10000.00 rpm 100 = 1 rpm
31.31 Frequency trip margin Real 0.00…10000.00 Hz 100 = 1 Hz
31.32 Emergency ramp supervision Real 0…300 % 1 = 1%
31.33 Emergency ramp supervision
delay
Real 0…100 s 1 = 1 s
31.40 Disable warning messages List 0…2 - 1 = 1
31.54 Fault action List 0…2 - 1 = 1
32 Supervision
32.01 Supervision status PB 0000h...FFFFh - 1 = 1
32.05 Supervision 1 function List 0…7 - 1 = 1
32.06 Supervision 1 action List 0…2 - 1 = 1
32.07 Supervision 1 signal Analog src --1 = 1
32.08 Supervision 1 filter time Real 0.000…30.000 s 1000 = 1 s
32.09 Supervision 1 low Real -21474830.00…
21474830.00
-100 = 1
32.10 Supervision 1 high Real -21474830.00…
21474830.00
-100 = 1
32.11 Supervision 1 hysteresis Real 0.00…100000.00 - 100 = 1
32.15 Supervision 2 function List 0…7 - 1 = 1
32.16 Supervision 2 action List 0…2 - 1 = 1
32.17 Supervision 2 signal Analog src --1 = 1
32.18 Supervision 2 filter time Real 0.000…30.000 s 1000 = 1 s
32.19 Supervision 2 low Real -21474830.00…
21474830.00
-100 = 1
No. Name Type Range Unit FbEq32
