114 Parameters
04.71 Event word 1 bit 15
code
Selects the hexadecimal code of an event (warning, fault
or pure event) whose status is shown as bit 15 of
parameter 04.40. See chapter Fault tracing (page 331) for
the event codes.
0X2330h
0000h…FFFFh Code of event. 1 = 1
05
05 Diagnostics
Various run-time-type counters and measurements
related to drive maintenance.
All parameters in this group are read-only unless
otherwise noted.
05.01 On-time counter Drive on-time counter. The counter runs when the drive is
powered.
-
0…65535 d On-time counter (number of days). 1 = 1 d
05.02 Run-time counter Motor run-time counter. The counter runs when the
inverter modulates.
-
0…65535 d Motor run-time counter. 1 = 1 d
05.03 Hours run Corresponding parameter to 05.02 Run-time counter in
hours, that is, 24 * 05.02 value + fractional part of a day.
-
0…
429496729.5 h
Hours. 1 = 1 h
05.04 Fan on-time counter Running time of the drive cooling fan. Can be reset from
the control panel by keeping Reset down for over 3
seconds.
-
0…65535 d Cooling fan run-time. 1 = 1 d
05.10 Control board
temperature
Measured temperature of the control board. -
-100… 300 °C or °F Temperature in degrees Celsius for Fahrenheit. 1 = unit
05.11 Inverter temperature Estimated drive temperature in percent of fault limit. The
fault limit varies according to the type of the drive.
0.0% = 0 °C (32 °F)
100.0% = Fault limit
-
-40.0…160.0% Temperature in percent. 1 = 1%
No. Name/Value Description Default
FbEq 16
ACS180 FW.book Page 114 Tuesday, March 9, 2021 2:25 PM
