Fieldbus control through the embedded fieldbus interface (EFB) 355
The new settings will take effect when the drive is powered up the next time, or when
they are validated by parameter 58.06 Communication control (Refresh settings).
Setting the drive control parameters
After the embedded fieldbus interface has been set up, check and adjust the drive
control parameters listed in the table below. The Setting for fieldbus control column
gives the value or values to use when the embedded fieldbus signal is the desired
source or destination for that particular drive control signal. The
Function/Information column gives a description of the parameter.
58.33 Addressing
mode
Mode 0 (default) Defines the mapping between parameters
and holding registers in the 400001…465536
(100…65535) Modbus register range.
58.34 Word order LO-HI (default) Defines the order of the data words in the
Modbus message frame.
58.101
…
58.114
Data I/O 1
…
Data I/O 14
For example, the
default settings
(I/Os 1…6 contain
the control word,
the status word,
two references and
two actual values)
Defines the address of the drive parameter
which the Modbus master accesses when it
reads from or writes to the register address
corresponding to Modbus In/Out parameters.
Select the parameters that you want to read
or write through the Modbus I/O words.
RO/DIO control
word, AO1 data
storage, Feedback
data storage,
Setpoint data
storage
These settings write the incoming data into
storage parameters 10.99 RO/DIO control
word, 13.91 AO1 data storage, 40.91
Feedback data storage or 40.92 Setpoint data
storage.
58.06 Communication
control
Refresh settings Validates the settings of the configuration
parameters.
Parameter
Setting for
fieldbus control
Function/Information
CONTROL COMMAND SOURCE SELECTION
20.01 Ext1
commands
Embedded fieldbus Selects fieldbus as the source for the start
and stop commands when EXT1 is selected
as the active control location.
20.06 Ext2
commands
Embedded fieldbus Selects fieldbus as the source for the start
and stop commands when EXT2 is selected
as the active control location.
SPEED REFERENCE SELECTION
22.11 Ext1 speed ref1 EFB ref1 Selects a reference received through the
embedded fieldbus interface as speed
reference 1.
Parameter
Setting for
fieldbus control
Function/Information
ACS180 FW.book Page 355 Tuesday, March 9, 2021 2:25 PM
