264 Parameters
0000h…FFFFh 1=1
49.219 Basic panel home
view 4
Selects the parameters that are shown in Home view 4 of
the integrated or Basic panel (ACS-BP-S).
For the selections, see parameter 49.19.
Auto
49.220 Basic panel home
view 5
Selects the parameters that are shown in Home view 5 of
the integrated or Basic panel (ACS-BP-S).
For the selections, see parameter 49.19.
Auto
49.221 Basic panel home
view 6
Selects the parameters that are shown in Home view 6 of
the integrated or Basic panel (ACS-BP-S).
For the selections, see parameter 49.19.
Auto
40
58 Embedded fieldbus
Configuration of the embedded fieldbus (EFB) interface.
See chapter Fieldbus control through the embedded
fieldbus interface (EFB).
58.01 Protocol enable Enables/disables the embedded fieldbus interface and
selects the protocol to use.
None
None None (communication disabled). 0
Modbus RTU Embedded fieldbus interface is enabled and uses the
Modbus RTU protocol.
1
58.02 Protocol ID Displays the protocol ID and revision.
This parameter is read-only.
-
Protocol ID and revision. 1 = 1
58.03 Node address Defines the node address of the drive on the fieldbus link.
Values 1…247 are allowable. Two devices with the same
address are not allowed on-line.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
1
0…255 Node address (values 1…127 are allowed). 1=1
No. Name/Value Description Default
FbEq 16
Bit Value
0 Motor data
1 Motor control
2 Control macros
3 Diagnostics
4 Reserved
5 Parameters
6...15 Reserved
