ABB ACS180 - Short Parameter Listing

104 Parameters
Short parameter listing
There are two parameter listings: Short and Long parameter listings.
The Short parameter listing shows common user parameters. The Long parameter
listing shows all user parameters including those in the Short parameter listing. The
default view is short listing. You can select the listing with parameter 96.02 Pass
code.
The following table lists the parameters that are visible in the Short parameter listing.
For full parameter descriptions, see the section Long parameter listing on page 108.
58 Embedded fieldbus Configuration of the embedded fieldbus (EFB) interface. 264
71 External PID1 Configuration of external PID. 272
95 HW configuration Various hardware-related settings. 274
96 System Language selection; access levels; macro selection; parameter
save and restore; control unit reboot; user parameter sets; unit
selection; parameter checksum calculation; user lock.
276
97 Motor control Switching frequency; slip gain; voltage reserve; flux braking; anti-
cogging (signal injection); IR compensation.
285
98 User motor parameters Motor values supplied by the user that are used in the motor
model.
289
99 Motor data Motor configuration settings. 291
Parameter
Input
password
Long and short listing selection
96.02 password
1 Short listing
2 Long listing
Par. No. Par. Name Settings/Range (default value on bold)
Group 99 Motor data
99.03 Motor type [0]Asynchronous motor, [1]Permanent magnet motor
99.04 Motor control mode [0]Vector, [1]Scalar
99.06 Motor nominal current depend on rating
99.07 Motor nominal voltage depend on rating
99.08 Motor nominal frequency depend on rating
99.09 Motor nominal speed depend on rating
99.10 Motor nominal power depend on rating
99.11 Motor nominal cos Φ 0.00 … 1.00
99.12 Motor nominal torque depend on rating
99.16 Motor phase order [0]UVW,[1]UWV
Group 01 Actual values (read-only)
1.01 Motor speed used -30000.00 … 30000.00 RPM
1.06 Output frequency -500.00 … 500.00 Hz
1.07 Motor current 0.00 … 30000.00 A
1.10 Motor torque -1600.00% … 1600.00%
Group Contents Page
