298 Parameters

Parameters supported by Modbus backwards compatibility

with 550

ACx550 compatibility mode is a way to communicate with an ACxx80 drive in such a

way that it looks like an ACx550 drive over Modbus RTU or Modbus TCP. This mode

can be enabled by changing parameter 96.78 550 compatibility mode to Enable.

In the 550 compatibility mode all supported parameters can be read as if the drive

were an ACx550. Some parameters are read only and do not support writes. See the

table below to see which parameters support writes.

ACx550

parameter

Name Read/Write

01.34 COMM RO WORD Read only

01.35 COMM VALUE 1 Read only

01.36 COMM VALUE 2 Read only

01.41 MWH COUNTER Read only

01.43 DRIVE ON TIME Read only

01.45 MOTOR TEMP Read only

01.50 CB TEMP Read only

01.74 SAVED KWH Read only

01.75 SAVED MWH Read only

01.77 SAVED AMOUNT 2 Read only

01.78 SAVED CO2 Read only

03.01 FB CMD WORD 1 Read only

03.02 FB CMD WORD 2 Read only

03.03 FB STS WORD 1 Read only

03.04 FB STS WORD 2 Read only

03.05 FAULT WORD 1 Read only

03.06 FAULT WORD 2 Read only

03.07 FAULT WORD 3 Read only

03.08 ALARM WORD 1 Read only

03.09 ALARM WORD 2 Read only

04.01 LAST FAULT Read only

04.12 PREVIOUS FAULT 1 Read only

04.13 PREVIOUS FAULT 2 Read only

10.01 EXT1 COMMANDS Read/Write

10.02 EXT2 COMMANDS Read/Write

10.03 DIRECTION Read/Write

10.04 JOGGING SEL Read/Write

11.02 EXT1/EXT2 SEL Read/Write

11.03 REF1 SELECT Read/Write

ACx550

parameter

Name Read/Write

01.01 SPEED & DIR Read only

01.02 SPEED Read only

01.03 OUTPUT FREQ Read only

01.04 CURRENT Read only

01.05 TORQUE Read only

01.06 POWER Read only

01.07 DC BUS VOLTAGE Read only

01.09 OUTPUT VOLTAGE Read only

01.10 DRIVE TEMP Read only

01.11 EXTERNAL REF 1 Read only

01.13 CTRL LOCATION Read only

01.14 RUN TIME Read only

01.15 KWH COUNTER Read only

01.18 DI 1-3 STATUS Read only

01.19 DI 4-6 STATUS Read only

01.20 AI 1 Read only

01.21 AI 2 Read only

01.22 RO 1-3 STATUS Read only

01.23 RO 4-6 STATUS Read only

01.24 AO 1 Read only

01.25 AO 2 Read only

01.26 PID 1 OUTPUT Read only

01.27 PID 2 OUTPUT Read only

01.28 PID 1 SETPNT Read only

01.29 PID 2 SETPNT Read only

01.30 PID 1 FBK Read only

01.31 PID 2 FBK Read only

01.32 PID 1 DEVIATION Read only

01.33 PID 2 DEVIATION Read only

ACS180 FW.book Page 298 Tuesday, March 9, 2021 2:25 PM
