ABB ACS180 - Page 299

Parameters 299
ACx550
parameter
Name Read/Write
21.05 DC HOLD SPEED Read/Write
21.06 DC CURR REF Read/Write
21.09 EMERG STOP SEL Read/Write
21.12 ZERO SPEED DELAY Read/Write
21.13 START DELAY Read/Write
22.02 ACCELER TIME 1 Read/Write
22.03 DECELER TIME 1 Read/Write
22.04 RAMP SHAPE 1 Read/Write
22.05 ACCELER TIME 2 Read/Write
22.06 DECELER TIME 2 Read/Write
22.07 RAMP SHAPE 2 Read/Write
22.08 EMERG DEC TIME Read/Write
23.01 PROP GAIN Read/Write
23.02 INTEGRATION TIME Read/Write
23.03 DERIVATION TIME Read/Write
23.04 ACC COMPENSATION Read/Write
30.02 PANEL COMM ERR Read/Write
30.03 EXTERNAL REF 1 Read/Write
30.04 EXTERNAL REF 2 Read/Write
30.05 MOT THERM POT Read/Write
30.06 MOT THERM TIME Read/Write
30.07 MOT LOAD CURVE Read/Write
30.08 ZERO SPEED LOAD Read/Write
30.09 BREAK POINT FREQ Read/Write
30.10 STALL FUNCTION Read/Write
30.11 STALL FREQUENCY Read/Write
30.12 STALL TIME Read/Write
30.17 EARTH FAULT Read/Write
30.18 COMM FAULT FUNC Read/Write
30.19 COMM FAULT TIME Read/Write
30.22 AI2 FAULT LIMIT Read/Write
30.23 WIRING FAULT Read/Write
33.01 FIRMWARE Read only
33.02 LOADING PACKAGE Read only
33.03 TEST DATE Read only
33.04 DRIVE RATING Read only
40.01 GAIN Read/Write
40.02 INTEGRATION TIME Read/Write
40.03 DERIVATION TIME Read/Write
ACx550
parameter
Name Read/Write
11.04 REF1 MIN Read/Write
11.05 REF1 MAX Read/Write
11.06 REF2 SEL Read/Write
11.07 REF2 MIN Read/Write
11.08 REF2 MAX Read/Write
12.01 CONST SPEED SEL Read/Write
12.02 CONST SPEED 1 Read/Write
12.03 CONST SPEED 2 Read/Write
12.04 CONST SPEED 3 Read/Write
12.05 CONST SPEED 4 Read/Write
12.06 CONST SPEED 5 Read/Write
12.07 CONST SPEED 6 Read/Write
15.02 CONST SPEED 7 Read/Write
15.03 AO1 CONTENT MAX Read/Write
15.04 MINIMUM AO1 Read/Write
15.05 MAXIMUM AO1 Read/Write
15.08 AO2 CONTENT MIN Read/Write
15.09 AO2 CONTENT MAX Read/Write
15.10 MINIMUM AO2 Read/Write
15.11 MAXIMUM AO2 Read/Write
16.01 RUN ENABLE Read/Write
16.02 PARAMETER LOCK Read/Write
16.03 PASS CODE Read/Write
16.08 START ENABLE 1 Read/Write
16.09 START ENABLE 2 Read/Write
20.01 MINIMUM SPEED Read/Write
20.02 MAXIMUM SPEED Read/Write
20.03 MAX CURRENT Read/Write
20.06 UNDERVOLT CRTL Read/Write
20.07 MINIMUM FREQ Read/Write
20.08 MAXIMUM FREQ Read/Write
20.13 MIN TORQUE SEL Read/Write
20.14 MAX TORQUE SEL Read/Write
20.15 MIN TORQUE 1 Read/Write
20.16 MIN TORQUE 2 Read/Write
20.17 MAX TORQUE 1 Read/Write
20.18 MAX TORQUE 2 Read/Write
21.02 STOP FUNCTION Read/Write
21.03 DC MAGN TIME Read/Write
