Parameters 111
01.63 Abs output frequency Absolute value of the output frequency 01.06 Output
frequency
-
0.00…500.00 Hz 1 = 1 Hz
01.64 Abs motor torque Absolute value of the motor torque 01.10 Motor torque.-
0.0…1600.0% 1 = 1%
01.65 Abs output power Absolute value of the output power 01.14 Output power.-
0.00…32767.00 kW 1 = 1 kW
01.66 Abs output power %
motor nom
Absolute value of the output power % of motor nominal
01.15 Output power % of motor nom.
-
0.00… 300.00% 1 = 1%
01.68 Abs motor shaft power Absolute value of the motor shaft power 01.17 Motor shaft
power.
-
0.00…332767.00 kW 1 = 1 kW
03
03 Input references
Values of references received from various sources.
All parameters in this group are read-only unless
otherwise noted.
03.01 Panel reference Local mode reference is given from the control panel. 0
-100000.00…
100000.00 rpm, Hz or
%
Control panel or PC tool reference. 1 = 10 unit
03.02 Panel reference
remote
Remote mode reference given from the control panel. -
-100000.00…
100000.00 rpm, Hz or
%
Control panel or PC tool reference. 1 = 10 unit
03.09 EFB reference 1 Scaled reference 1 received through the embedded
fieldbus interface. The scaling is defined by 58.26 EFB
ref1 type
-
-30000.00 …
30000.00
Scaled reference 1 received through the embedded
fieldbus interface.
1 = 10
03.10 EFB reference 2 Scaled embedded fieldbus reference 2. -
-30000.00 …
30000.00
Scaled reference 2 received through the embedded
fieldbus interface. The scaling is defined by 58.27 EFB
ref2 type
1 = 10
03.17 Integrated Panel ref Local mode reference given from the integrated control
panel. The unit (rpm, Hz or %) is set from parameter.
0
-100000.00 …
100000.00 rpm, Hz or
%
Integrated control panel reference. 1 = 10
03.18 Integrated Panel ref
remote
Remote mode reference given from the integrated control
panel.
0
-100000.00 …
100000.00 rpm, Hz or
%
Integrated control panel reference. 1 = 10
No. Name/Value Description Default
FbEq 16
