Parameters 269
Torque Torque reference. The scaling is defined by parameter
46.03 Torque scaling.
3
Speed Speed reference. The scaling is defined by parameter
46.01 Speed scaling.
4
Frequency Frequency reference. The scaling is defined by parameter
46.02 Frequency scaling.
5
58.27 EFB ref2 type Selects the type and scaling of reference 2 received
through the embedded fieldbus interface.
The scaled reference is displayed by 03.10 EFB reference
2.
Speed or
frequency
58.28 EFB act1 type Selects the type/source and scaling of actual value 1
transmitted to the fieldbus.network through the embedded
fieldbus interface.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent The value selected by parameter 58.31 EFB act1
transparent source is sent as actual value 1. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
1
General The value selected by parameter 58.31 EFB act1
transparent source is sent as actual value 1 with a 16-bit
scaling of 100 =1 unit (ie. integer and two decimals).
2
Torq ue 01.10 Motor torque is sent as actual value 1. Scaling is
defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 1. Scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 1. Scaling
is defined by parameter 46.02 Frequency scaling.
5
58.29 EFB act2 type Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through the embedded
fieldbus interface.
Transparent
Speed or frequency Type/source and scaling are chosen automatically
according to the currently active operation mode as
follows:
0
No. Name/Value Description Default
FbEq 16
Operation mode
(see par. 19.01)
Actual 1 type (source) Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling
Operation mode
(see par. 19.01)
Actual 1 type (source) Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling
