270 Parameters
Transparent The value selected by parameter 58.32 EFB act2
transparent source is sent as actual value 2. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
1
General The value selected by parameter 58.32 EFB act2
transparent source is sent as actual value 2 with a 16-bit
scaling of 100 =1 unit (i.e. integer and two decimals).
2
Torque 01.10 Motor torque is sent as actual value 2. Scaling is
defined by parameter 46.03 Torque scalingg.
3
Speed 01.01 Motor speed used is sent as actual value 2. Scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 2. Scaling
is defined by parameter 46.02 Frequency scaling.
5
58.31 EFB act1 transparent
source
Selects the source of actual value 1 when parameter
58.28 EFB act1 type is set to Transparent.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations). -
58.32 EFB act2 transparent
source
Selects the source of actual value 1 when parameter
58.29 EFB act2 type is set to Transparent.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations). -
58.33 Addressing mode Defines the mapping between parameters and holding
registers in the 400101…465535 Modbus register range.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
Mode 0
Mode 0 16-bit values (groups 1…99, indexes 1…99)
:
Register address = 400000 + 100 × parameter group +
parameter index. For example, parameter 22.80 would be
mapped to register 400000 + 2200 + 80 = 402280.
32-bit values (groups 1…99, indexes 1…99)
:
Register address = 420000 + 200 × parameter group +
2 × parameter index. For example, parameter 22.80
would be mapped to register 420000 + 4400 + 160 =
424560.
0
Mode 1 16-bit values (groups 1…255, indexes 1…255)
:
Register address = 400000 + 256 × parameter group +
parameter index. For example, parameter 22.80 would be
mapped to register 400000 + 5632 + 80 = 405712.
1
Mode 2 32-bit values (groups 1…127, indexes 1…255)
:
Register address = 400000 + 512 × parameter group +
2 × parameter index. For example, parameter 22.80
would be mapped to register 400000 + 11264 + 160 =
411424.
2
58.34 Word order Selects in which order 16-bit registers of 32-bit
parameters are transferred.
For each register, the first byte contains the high order
byte and the second byte contains the low order byte.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
LO-HI
HI-LO The first register contains the high order word, the second
contains the low order word.
0
No. Name/Value Description Default
FbEq 16
