Parameters 265
58.04 Baud rate Selects the transfer rate of the fieldbus link.
When using selection Autodetect, the parity setting of the
bus must be known and configured in parameter 58.05
Parity. When parameter 58.04 Baud rate is set to
Autodetect, the EFB settings must be refreshed with
parameter 58.06. The bus is monitored for a period of time
and the detected baud rate is set as the value of this
parameter.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
19.2 kbps
Autodetect Baud rate detected automatically. 0
4.8 kbps 4.8 kbit/s. 1
9.6 kbps 9.6 kbit/s. 2
19.2 kbps 19.2 kbit/s. 3
38.4 kbps 38.4 kbit/s. 4
57.6 kbps 57.6 kbit/s. 5
76.8 kbps 76.8 kbit/s. 6
115.2 kbps 115.2 kbit/s. 7
58.05 Parity Selects the type of parity bit and number of stop bits.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
8 EVEN 1
8 NONE 1 Eight data bits, no parity bit, one stop bit. 0
8 NONE 2 Eight data bits, no parity bit, two stop bits. 1
8 EVEN 1 Eight data bits, even parity bit, one stop bit. 2
8 ODD 1 Eight data bits, odd parity bit, one stop bit. 3
58.06 Communication
control
Takes changed EFB settings in use, or activates silent
mode.
Enabled
Enabled Normal operation. 0
Refresh settings Refreshes settings (Modbus parameters 58.01…58.05,
58.14…58.17, 58.25, 58.28…58.34) and takes changed
EFB configuration settings in use.
Reverts automatically to Enabled.
1
Silent mode Activates silent mode (no messages are transmitted).
Silent mode can be terminated by activating the Refresh
settings selection of this parameter.
2
No. Name/Value Description Default
FbEq 16
