ABB ACS180 - Page 325

Additional parameter data 325
49.20 Basic panel home view 2 - -
49.21 Basic panel home view 3 - -
49.30 Basic panel menu hiding 0000h…FFFFh -
49.219 Basic panel home view 4 0000h…FFFFh -
49.220 Basic panel home view 5 0000h…FFFFh -
49.221 Basic panel home view 6 0000h…FFFFh -
58 Embedded fieldbus
58.01 Protocol enable List 0, 1, 3 - 1 = 1
58.02 Protocol ID Real 0…65535 - 1 = 1
58.03 Node address
Node ID
Real 0…255 - 1 = 1
58.04 Baud rate List 0…7 - 1 = 1
58.05 Parity List 0…3 - 1 = 1
58.06 Communication control List 0…2 - 1 = 1
58.07 Communication diagnostics PB 0000h…FFFFh - 1 = 1
58.08 Received packets Real 0…4294967295 - 1 = 1
58.09 Transmitted packets Real 0…4294967295 - 1 = 1
58.10 All packets Real 0…4294967295 - 1 = 1
58.11 UART errors Real 0…4294967295 - 1 = 1
58.12 CRC errors Real 0…4294967295 - 1 = 1
58.14 Communication loss action List 0…4 - 1 = 1
58.15 Communication loss mode List 0…2 - 1 = 1
58.16 Communication loss time Real 0.0…6000.0 s 10 = 1 s
58.17 Transmit delay Real 0…65535 ms 1 = 1 ms
58.18 EFB control word PB 0...FFFFFFFFh - 1 = 1
58.19 EFB status word PB 0...FFFFFFFFh - 1 = 1
58.25 Control profile List 0, 5, 7, 8, 9 - 1 = 1
58.26 EFB ref1 type List 0…5 - 1 = 1
58.27 EFB ref2 type List 0…5 - 1 = 1
58.28 EFB act1 type List 0…5 - 1 = 1
58.29 EFB act2 type List 0…5 - 1 = 1
58.31 EFB act1 transparent source Analog src --1 = 1
58.32 EFB act2 transparent source Analog src --1 = 1
58.33 Addressing mode List 0…2 - 1 = 1
58.34 Word order List 0…1 - 1 = 1
58.70 EFB debug mode List -100000...100000 - 1 = 1
58.71 EFB reference 1 Real -100000...100000 - 1 = 1
58.72 EFB reference 2 Real -100000...100000 - 1 = 1
58.73 EFB actual value 1 Real -100000...100000 - 1 = 1
58.74 EFB actual value 2 Real -100000...100000 - 1 = 1
58.101 Data I/O 1 Analog src --1 = 1
