Parameters 117
06
06 Control and status
words
Drive control and status words.
06.01 Main control word The main control word of the drive. This parameter shows
the control signals as received from the selected sources
(such as digital inputs, the fieldbus interfaces and the
application program).
The bit assignments of the word are as described on page
360. The related status word are presented on pages 360.
This parameter is read-only.
Note: With the fieldbus control, the parameter value is not
same as the value that it receives from the PLC.
0000h
0000h…FFFFh Main control word. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name
0 OFF1_ CONTROL
1 OFF2_ CONTROL
2 OFF3_ CONTROL
3 INHIBIT_ OPERATION
4 RAMP_OUT_ ZERO
5 RAMP_HOLD
6 RAMP_IN_ ZERO
7 RESET
8 JOGGING_1
9 JOGGING_2
10 REMOTE_ CMD
11 EXT_CTRL_ LOC
12 USER_0
13 USER_1
14 USER_2
15 USER_3
