Additional parameter data 307
Parameter groups 10…99
No. Name Type Range Unit FbEq32
10 Standard DI, RO
10.01 DI status PB 0000h…FFFFh - 1 = 1
10.02 DI delayed status PB 0000h…FFFFh - 1 = 1
10.03 DI force selection PB 0000h…FFFFh - 1 = 1
10.04 DI forced data PB 0000h…FFFFh - 1 = 1
10.04 DI forced data PB 0000h…FFFFh - 1 = 1
10.05 DI1 ON delay PB 0.0…3000.0 s 10 = 1 s
10.06 DI1 OFF delay PB 0.0…3000.0 s 10 = 1 s
10.07 DI2 ON delay PB 0.0…3000.0 s 10 = 1 s
10.08 DI2 OFF delay PB 0.0…3000.0 s 10 = 1 s
10.09 DI3 ON delay PB 0.0…3000.0 s 10 = 1 s
10.10 DI3 OFF delay PB 0.0…3000.0 s 10 = 1 s
10.11 DI4 ON delay PB 0.0…3000.0 s 10 = 1 s
10.12 DI4 OFF delay PB 0.0…3000.0 s 10 = 1 s
10.13 DI5 ON delay PB 0.0…3000.0 s 10 = 1 s
10.14 DI5 OFF delay PB 0.0…3000.0 s 10 = 1 s
10.21 RO status PB 0000h…FFFFh - 1 = 1
10.22 RO force selection PB 0000h…FFFFh - 1 = 1
10.23 RO forced data PB 0000h…FFFFh - 1 = 1
10.24 RO1 source Binary src --1 = 1
10.25 RO1 ON delay Real 0.0…3000.0 s 10 = 1 s
10.26 RO1 OFF delay Real 0.0…3000.0 s 10 = 1 s
10.99 RO/DIO control word PB 0000h…FFFFh - 1 = 1
10.101 RO1 toggle counter Real 0…4294967000 - 1 = 1
11 Standard DIO, FI, FO
11.02 DIO delayed status PB 0000h…FFFFh - 1 = 1
11.03 DIO force selection PB 0000h…FFFFh - 1 = 1
11.04 DO1 force data PB 0000h…FFFFh - 1 = 1
11.06 DO1 output source Binary src --1 = 1
11.07 DO1 ON delay Real 0.0…3000.0 s 10 = 1 s
11.08 DO1 OFF delay Real 0.0…3000.0 s 10 = 1 s
11.13 DI3 configuration List 0, 1 - 1 = 1
11.17 DI4 configuration List 0, 1 - 1 = 1
11.21 DI5 configuration List 0, 1 - 1 = 1
11.38 Freq in 1 actual value Real 0…16000 Hz 1 = 1 Hz
11.39 Freq in 1 scaled value Real -32768.000…32767.000 - 1000 = 1
11.42 Freq in 1 min Real 0…16000 Hz 1 = 1 Hz
11.43 Freq in 1 max Real 0…16000 Hz 1 = 1 Hz
11.44 Freq in 1 at scaled min Real -32768.000…32767.000 - 1000 = 1
ACS180 FW.book Page 307 Tuesday, March 9, 2021 2:25 PM
