ABB ACS180 - Standard DI, RO

Parameters 123
09
10 Standard DI, RO
Configuration of digital inputs and relay outputs.
10.01 DI status Displays the status of digital inputs. 0000h
0000h…FFFFh Status of digital inputs. 1 = 1
10.02 DI delayed status Displays the status of digital inputs. This word is updated
only after activation / deactivation delays.
0000h
0000h…FFFFh Delayed status of digital inputs. 1 = 1
10.03 DI force selection Selects the digital inputs, states of which will be controlled
by parameter 10.04 DI forced data. A bit in parameter
10.04 DI forced data is provided for each digital input, and
its value is applied whenever the corresponding bit in this
parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 10.03 and 10.04).
0000h
0000h…FFFFh Override selection for digital inputs. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Value
0 DI1 = Status of digital input 1.
1 DI2 = Status of digital input 2.
2 DI3 = Status of digital input 3.
3 DI4 = Status of digital input 4.
4 DI5 = Status of digital input 5.
6...15 Reserved.
Bit Value
0 DI1 = Delayed status of digital input 1.
1 DI2 = Delayed status of digital input 2.
2 DI3 = Delayed status of digital input 3.
3 DI4 = Delayed status of digital input 4.
4 DI5 = Delayed status of digital input 5.
6...15 Reserved.
Bit Value
0 1 = Force DI1 to value of bit 0 of parameter 10.04 DI forced data.
1 1 = Force DI2 to value of bit 1 of parameter 10.04 DI forced data.
2 1 = Force DI3 to value of bit 2 of parameter 10.04 DI forced data.
3 1 = Force DI4 to value of bit 3 of parameter 10.04 DI forced data.
4 1 = Force DI5 to value of bit 4 of parameter 10.04 DI forced data.
5...15 Reserved.
