322 Additional parameter data
41.47 Set 2 wake-up deviation Real -200000.00… 200000.00 PID
customer
units
100 = 1 PID
customer unit
41.48 Set 2 wake-up delay Real 0.00…60.00 s 100 = 1 s
41.49 Set 2 tracking mode Binary src --1 = 1
41.50 Set 2 tracking ref selection Analog src --1 = 1
41.51 Set 2 trim mode List 0...3 - 1 = 1
41.52 Set 2 trim selection List 1...3 - 1 = 1
41.53 Set 2 trimmed ref pointer Analog src --1 = 1
41.54 Set 2 trim mix Real 0.000...1.000 - 1 = 1
41.55 Set 2 trim adjust Real -100.000...100.000 - 1 = 1
41.56 Set 2 trim source List 1...2 - 1 = 1
41.58 Set 2 increase prevention List 0…3 - 1 = 1
41.59 Set 2 decrease prevention List 0…3 - 1 = 1
41.60 Set 2 PID activation source Binary src --1 = 1
41.79 Set 2 units List --1=1
41.80 Set 2 PID output min source List 0…1 - 1 = 1
41.81 Set 2 PID output max source List 0…1 - 1 = 1
41.89 Set 2 setpoint multiplier Real -200000.00…200000.00 - 100 = 1
41.90 Set 2 feedback multiplier Real -200000.00…200000.00 - 100 = 1
44 Mechanical brake control
44.01 Brake control status PB 0000h…FFFFh - 1 = 1
44.06 Brake control enable Binary src --1 = 1
44.08 Brake open delay Real 0.00…5.00 s 100 = 1 s
44.13 Brake close delay Real 0.00…60.00 s 100 = 1 s
44.14 Brake close level Real 0.0…1000.0 rpm 100 = 1 rpm
44.202 Torque proving Binary src --1 = 1
44.203 Torque proving reference Real 0.0...300.0 % 10 = 1.0%
44.204 Brake system check time Real 0.10…30 ms 10 = 1 s
44.205 Brake slip speed limit Real 0.0 … 30000.0 rpm 1 = 1 rpm
44.206 Brake slip fault delay Real 0…30000 ms 1 = 1 ms
44.207 Safety close select Binary src --1 = 1
44.208 Safety close speed Real 0.00 … 30000.00 rpm 1 = 1 rpm
44.209 Safety close delay Real 0…30000 ms 1 = 1 ms
44.211 Extended runtime Real 0.0…3600.0 s 1000 = 1 s
44.212 Extended runtime sw Binary src 0000h...FFFFh - -
45 Energy efficiency
45.01 Saved GW hours Real 0…65535 GWh 1 = 1 GWh
45.02 Saved MW hours Real 0…999 MWh 1 = 1 MWh
45.03 Saved kW hours Real 0.0…999.0 kWh 10 = 1 kWh
45.04 Saved energy Real 0.0…214748364.7 kWh 10 = 1 kWh
No. Name Type Range Unit FbEq32
