44 Mechanical brake
control
Configuration of mechanical brake control.
44.01 Brake control status Displays the mechanical brake control status word.
This parameter is read-only.
0000h
0000h…FFFFh Mechanical brake control status word. 1 = 1
44.06 Brake control enable Activates/deactivates (or selects a source that
activates/deactivates) the mechanical brake control logic.
0 = Brake control inactive
1 = Brake control active
Not selected
Not selected The brake control function is disabled. 0
Selected The brake control function is enabled. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status 24
Supervision 2 Bit 1 of 32.01 Supervision status 25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.x 29
Other [bit] Source selection (see Terms and abbreviations). -
No. Name/Value Description Default
FbEq 16
Bit Name Information
0 Open command Close/open command to brake actuator (0 = close, 1 = open).
Connect this bit to desired output.
1 Opening torque
request
1 = Opening torque requested from drive logic
2 Hold stopped
request
1 = Hold requested from drive logic
3 Ramp to stopped 1 = Ramping down to zero speed requested from drive logic
4 Enabled 1 = Brake control is enabled
5 Closed 1 = Brake control logic in BRAKE CLOSED state
6 Opening 1 = Brake control logic in BRAKE OPENING state
7 Open 1 = Brake control logic in BRAKE OPEN state
8 Closing 1 = Brake control logic in BRAKE CLOSING state
9…15 Reserved
