Parameters 185
26.71 Torque reference act 2 Displays the value of torque reference source 2 (selected
by parameter 26.12 Torque ref2 source). See the control
chain diagram on page 383.
This parameter is read-only.
-
-1600.0…1600.0% Value of torque reference source 2. See par.
46.03
26.72 Torque reference act 3 Displays the torque reference after the function applied by
parameter 26.13 Torque ref1 function (if any), and after
selection (26.14 Torque ref1/2 selection). See the control
chain diagram on page 383.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference after selection. See par.
46.03
26.73 Torque reference act 4 Displays the torque reference after application of
reference additive 1. See the control chain diagram on
page 383.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference after application of reference additive 1. See par.
46.03
26.74 Torque ref ramp out Displays the torque reference after limiting and ramping.
See the control chain diagram on page 383.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference after limiting and ramping. See par.
46.03
26.75 Torque reference act 5 Displays the torque reference after control mode
selection. See the control chain diagram on page 384.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference after control mode selection. See par.
46.03
26.76 Torque reference act 6 Displays the torque reference after torque trim. See the
control chain diagram on page 384.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference See par.
46.03
26.81 Rush control gain Rush controller gain term. See section Rush control
(page 57).
5.0
0.0 …10000.0 Rush controller gain (0.0 = disabled). 1 = 1
26.82 Rush control
integration time
Rush controller integration time term. 2.0 s
0.0 …10.0 s Rush controller integration time (0.0 = disabled). 1 = 1 s
28
28 Frequency reference
chain
Settings for the frequency reference chain.
See the control chain diagrams on pages 383 and 384.
28.01 Frequency ref ramp
input
Displays the used frequency reference before ramping.
See the control chain diagram on page 383.
This parameter is read-only.
-
-500.00…500.00 Hz Frequency reference before ramping. See par.
46.02
No. Name/Value Description Default
FbEq 16
