Additional parameter data 313
26.20 Torque reversal List --1 = 1
26.70 Torque reference act 1 Real -1600.0…1600.0 % 10 = 1%
26.71 Torque reference act 2 Real -1600.0…1600.0 % 10 = 1%
26.72 Torque reference act 3 Real -1600.0…1600.0 % 10 = 1%
26.73 Torque reference act 4 Real -1600.0…1600.0 % 10 = 1%
26.74 Torque ref ramp out Real -1600.0…1600.0 % 10 = 1%
26.75 Torque reference act 5 Real -1600.0…1600.0 % 10 = 1%
26.76 Torque reference act 6 Real -1600.0…1600.0 % 10 = 1%
26.81 Rush control gain Real 0.0 … 10000.0 - 10 = 1
26.82 Rush control integration time Real 0.0 … 10.0 s 10 = 1 s
28 Frequency reference chain
28.01 Frequency ref ramp input Real -500.00…500.00 Hz 100 = 1 Hz
28.02 Frequency ref ramp output Real -500.00…500.00 Hz 100 = 1 Hz
28.11 Ext1 frequency ref1 Analog src --1 = 1
28.12 Ext1 frequency ref2 Analog src --1 = 1
28.13 Ext1 frequency function List 0…6 - 1 = 1
28.15 Ext2 frequency ref1 Analog src --1 = 1
28.16 Ext2 frequency ref2 Analog src - - 1 = 1
28.17 Ext2 frequency function List 0…6 - 1 = 1
28.21 Constant frequency function PB 0000h...FFFFh - 1 = 1
28.22 Constant frequency sel1 Binary src --1 = 1
28.23 Constant frequency sel2 Binary src --1 = 1
28.24 Constant frequency sel3 Binary src --1 = 1
28.26 Constant frequency 1 Real -500.00…500.00 Hz 100 = 1 Hz
28.27 Constant frequency 2 Real -500.00…500.00 Hz 100 = 1 Hz
28.28 Constant frequency 3 Real -500.00…500.00 Hz 100 = 1 Hz
28.29 Constant frequency 4 Real -500.00…500.00 Hz 100 = 1 Hz
28.30 Constant frequency 5 Real -500.00…500.00 Hz 100 = 1 Hz
28.31 Constant frequency 6 Real -500.00…500.00 Hz 100 = 1 Hz
28.32 Constant frequency 7 Real -500.00…500.00 Hz 100 = 1 Hz
28.41 Frequency ref safe Real -500.00…500.00 Hz 100 = 1 Hz
28.42 Jogging 1 frequency ref Real -500.00…500.00 Hz 100 = 1 Hz
28.43 Jogging 2 frequency ref Real -500.00…500.00 Hz 100 = 1 Hz
28.51 Critical frequency function PB 00b…11b - 1 = 1
28.52 Critical frequency 1 low Real -500.00…500.00 Hz 100 = 1 Hz
28.53 Critical frequency 1 high Real -500.00…500.00 Hz 100 = 1 Hz
28.54 Critical frequency 2 low Real -500.00…500.00 Hz 100 = 1 Hz
28.55 Critical frequency 2 high Real -500.00…500.00 Hz 100 = 1 Hz
28.56 Critical frequency 3 low Real -500.00…500.00 Hz 100 = 1 Hz
28.57 Critical frequency 3 high Real -500.00…500.00 Hz 100 = 1 Hz
28.71 Freq ramp set selection Binary src --1 = 1
