118 Parameters
06.11 Main status word ABB Drives Profile Main status word. Reflects the status
of the drive irrespective of control source e.g. a fieldbus
system, control panel (keypad), PC-Tool, standard I/O,
application program or sequence programming, and
irrespective of the actual control profile which is used to
control the drive.
The bit assignments are described on page 363 (Contents
of the fieldbus control word). The state diagram (valid for
ABB drives profile) is on page 365.
This parameter is read-only.
Note: With the fieldbus control, the parameter value is not
same as the value that it receives from the PLC.
0000h
0000h…FFFFh Main status word. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name
0 RDY_ON
1 RDY_RUN
2 RDY_REF
3 TRIPPED
4 OFF_2_STATUS
5 OFF_3_STATUS
6 SWC_ON_ INHIB
7 ALARM
8 AT_ SETPOINT
9 REMOTE
10 ABOVE_ LIMIT
11 USER_0
12 USER_1
13 USER_2
14 USER_3
15 Reserved
ACS180 FW.book Page 118 Tuesday, March 9, 2021 2:25 PM
