Parameters 119
06.16 Drive status word 1 Drive status word 1.
This parameter is read-only.
-
0000h…FFFFh Drive status word 1. 1 = 1
06.17 Drive status word 2 Drive status word 2.
This parameter is read-only.
-
0000h…FFFFh Drive status word 2. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Enabled 1 = Both run enable (see par. 20.12) and start enable (20.19) signals
are present. Note: This bit is not affected by the presence of a fault.
1 Inhibited 1 = Start inhibited. To start the drive, the inhibiting signal (see par.
06.18) must be removed and the start signal cycled.
2 DC charged 1 = DC circuit has been charged
3 Ready to start 1 = Drive is ready to receive a start command
4 Following
reference
1 = Drive is ready to follow given reference
5 Started 1 = Drive has been started
6 Modulating 1 = Drive is modulating (output stage is being controlled)
7 Limiting 1 = Any operating limit (speed, torque, etc.) is active
8 Local control 1 = Drive is in local control
10 Ext1 active 1 = Control location EXT1 active
11 Ext2 active 1 = Control location EXT2 active
12 Reserved
13 Start request 1 = Start requested. 0 = When Enable to rotate signal (see par.
20.22) is 0 (rotating of the motor is disabled).
14 Running 1 = Drive is running
15 Reserved
Bit Name Description
0 Identification run done 1 = Motor identification (ID) run has been performed
1 Magnetized 1 = The motor has been magnetized
2 Torque control 1 = Torque control mode active
3 Speed control 1 = Speed control mode active
4 Reserved
5 Safe reference active 1 = A “safe” reference is applied by functions such as
parameters 49.05
6 Last speed active 1 = A “last speed” reference is applied by functions such as
parameters 49.05
7 Reserved
8 Emergency stop failed 1 = Emergency stop failed (see parameters 31.32 and 31.33)
9 Jogging active 1 = Jogging enable signal is on
10 Above limit Actual speed, frequency or torque equals or exceeds the limit
(defined by parameters 46.31...45.33). Valid for both directions
of rotation.
11…12 Reserved
13 Start delay active 1 = Start delay (par. 21.22) active.
14…15 Reserved
