260 Parameters
46.23 At torque hysteresis Defines the “at setpoint” limits for torque control of the
drive. When the absolute difference between reference
(26.73 Torque reference act 4) and actual torque (01.10
Motor torque) is smaller than 46.23 At torque hysteresis,
the drive is considered to be “at setpoint”. This is indicated
by bit 8 of 06.11 Main status word
5.0%
0.0…300.0% Limit for “at setpoint” indication in torque control. See par.
46.03
46.31 Above speed limit Defines the trigger level for “above limit” indication in
speed control. This is indicated by bit 10 of parameter
06.11 and parameter 06.17. When actual speed exceeds
the limit, bit 10 of 06.17 Drive status word 2 is set.
1500.00 rpm
0.00…30000.00 rpm “Above limit” indication trigger level for speed control. See par.
46.01
46.32 Above frequency limit Defines the trigger level for “above limit” indication in
frequency control. This is indicated by bit 10 of parameter
06.11 and parameter 06.17. When actual frequency
exceeds the limit, bit 10 of 06.17 Drive status word 2 is
set.
50.00 Hz
0.00…1000.00 Hz “Above limit” indication trigger level for frequency control. See par.
46.02
46.33 Above torque limit Defines the trigger level for “above limit” indication in
torque control. This is indicated by bit 10 of parameter
06.11 and parameter 06.17. When actual torque exceeds
the limit, bit 10 of 06.17 Drive status word 2 is set.
300.0%
0.0…1600.0% “Above limit” indication trigger level for torque control. See par.
46.03
46.41 kWh pulse scaling Defines the trigger level for the “kWh pulse” on for 50 ms.
The output of the pulse is bit 9 of 05.22 Diagnostic word 3.
1.000 kWh
0.001…
1000.000 kWh
“kWh pulse” on trigger level. 1 = 1 kWh
No. Name/Value Description Default
FbEq 16
01.10 (%)
0%
26.73 + 46.23(%)
26.73 (%)
26.73 - 46.23 (%)
Drive at setpoint
(06.11 bit 8 = 1)
