20.09 Ext2 in2 source Selects source 2 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1 in1
source.
Always off
20.10 Ext2 in3 source Selects source 3 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1 in1
source.
Always off
20.11 Run enable stop mode Selects the way the motor is stopped when the run enable
signal switches off.
The source of the run enable signal is selected by
parameter 20.12 Run enable 1 source.
Coast
Coast Stop by switching off the output semiconductors of the
drive. The motor coasts to a stop.
WARNING! If a mechanical brake is used, ensure
it is safe to stop the drive by coasting.
0
Ramp Stop along the active deceleration ramp. See parameter
group 23 Speed reference ramp.
1
Torque limit Stop according to torque limits (parameters 30.19 and
30.20).
2
20.12 Run enable 1 source Selects the source of the external run enable signal. If the
run enable signal is switched off, the drive will not start. If
already running, the drive will stop according to the setting
of parameter 20.11 Run enable stop mode.
1 = Run enable signal on.
See also parameter 20.19 Enable start command
Selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status.24
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
EFB MCW bit 3 Control word bit 3 received through the embedded
fieldbus interface.
32
Other [bit] Source selection (see Terms and abbreviations). -
20.19 Enable start command Selects the source for the start enable signal.
1 = Start enable.
With the signal switched off, any drive start command is
inhibited. (Switching the signal off while the drive is
running will not stop the drive.)
See also parameter 20.12 Run enable 1 source.
On
Off 0. 0
