144 Parameters
Integrated Panel Start; stop and direction commands from Integrated Panel 23
20.02 Ext1 start trigger type Defines whether the start signal for external control
location EXT1 is edge-triggered or level-triggered.
Note: This parameter is not effective if a pulse-type start
signal is selected. See the descriptions of the selections of
parameter 20.01 Ext1 commands.
Level
Edge The start signal is edge-triggered. 0
Level The start signal is level-triggered. 1
20.03 Ext1 in1 source Selects source 1 for parameter 20.01 Ext1 commands. DI1
Always off 0 (always off). 0
Always on 1 (always on). 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status.24
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
20.04 Ext1 in2 source Selects source 2 for parameter 20.01 Ext1 commands.
For the available selections, see parameter 20.03 Ext1
in1 source.
DI2
20.05 Ext1 in3 source Selects source 3 for parameter 20.01 Ext1 commands.
For the available selections, see parameter 20.03 Ext1
in1 source.
Always off
20.06 Ext2 commands Selects the source of start, stop and direction commands
for external control location 2 (EXT2).
See also parameters 20.07…20.10. See parameter 20.21
for the determination of the actual direction.
Not selected
Not selected No start or stop command sources selected. 0
In1 Start The source of the start and stop commands is selected by
parameter 20.08 Ext2 in1 source. The state transitions of
the source bits are interpreted as follows:
1
No. Name/Value Description Default
FbEq 16
State of source 1 (20.08) Command
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
Start
0Stop
