266 Parameters
58.07 Communication
diagnostics
Displays the status of the EFB communication.
This parameter is read-only.
Note that the name is only visible when the error is
present (bit value is 1).
-
0000h…FFFFh EFB communication status. 1 = 1
58.08 Received packets Displays a count of valid packets addressed to the drive.
During normal operation, this number increases
constantly.
Can be reset from the control panel by keeping Reset
down for over 3 seconds.
-
0…4294967295 Number of received packets addressed to the drive. 1 = 1
58.09 Transmitted packets Displays a count of valid packets transmitted by the drive.
During normal operation, this number increases
constantly.
Can be reset from the control panel by keeping Reset
down for over 3 seconds.
-
0…4294967295 Number of transmitted packets. 1 = 1
58.10 All packets Displays a count of valid packets addressed to any device
on the bus. During normal operation, this number
increases constantly.
Can be reset from the control panel by keeping Reset
down for over 3 seconds.
-
0…4294967295 Number of all received packets. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Init failed 1 = EFB initialization failed
1 Addr config err 1 = Node address not allowed by protocol
2 Silent mode 1 = Drive not allowed to transmit
0 = Drive allowed to transmit
3 Autobauding
4 Wiring error 1 = Errors detected (A/B wires possibly swapped)
5 Parity error 1 = Error detected: check parameters 58.04 and 58.05
6 Baud rate error 1 = Error detected: check parameters 58.05 and 58.04
7 No bus activity 1 = 0 bytes received during last 5 seconds
8 No packets 1 = 0 packets (addressed to any device) detected during last 5
seconds
9 Noise or addressing
error
1 = Errors detected (interference, or another device with the
same address on line)
10 Comm loss 1 = 0 packets addressed to the drive received within timeout
(58.16)
11 CW/Ref loss 1 = No control word or references received within timeout (58.16)
12 Not active Reserved
13 Protocol 1 Reserved
14 Protocol 2 Reserved
15 Internal error 1 = Internal errors detected
ACS180 FW.book Page 266 Tuesday, March 9, 2021 2:25 PM
