Parameters 105
1.11 DC voltage 0.00 … 2000.00 V
1.13 Output voltage 0 … 2000 V
1.14 Output power -32768.00 … 32767.00 kW
Group 5 Diagnostics (read-only)
5.02 Run-time counter 0 … 65535 days
5.11 Inverter temperature -40.0 … 160.0 %
Group 10 Standard DI, RO
10.24 RO1 source [2]Ready run, [7]Running, [14]Fault, [16]Fault/Warning
Group 11 Standard DI, RO
11.06 DO1 output source [2]Ready run, [7]Running, [14]Fault, [16]Fault/Warning
11.21 DI5 configuration [0]Digital input, [1]Analog input
Group 12 Standard AI
12.15 AI1 unit selection [2]V, [10]mA
12.17 AI1 min -22.000 … 22.000 mA or V, 0mA or 0V
12.18 AI1 max -22.000 … 22.000 mA or V, 20mA or 10V
12.19 AI1 scaled at AI1 min -32768.000 … 32767.000, 0
12.20 AI1 scaled at AI1 max -32768.000 … 32767.000, 50
12.25 AI2 unit selection [2]V, [10]mA
12.27 AI2 min -22.000 … 22.000 mA or V, 0mA or 0V
12.28 AI2 max -22.000 … 22.000 mA or V, 20mA or 10V
12.29 AI2 scaled at AI2 min -32768.000 … 32767.000, 0
12.30 AI2 scaled at AI2 max -32768.000 … 32767.000, 50
Group 13 Standard AO
13.12 AO1 source [3]Output frequency, [4]Motor current
13.15 AO1 unit selection [2]V, [10]mA
13.17 AO1 source min -32768.000 … 32767.000, 0
13.18 AO1 source max -32768.000 … 32767.000, 50
13.19 AO1 out at AO1 src min -22.000 … 22.000 mA or V, 0mA or 0V
13.20 AO1 out at AO1 src max -22.000 … 22.000 mA or V, 20mA or 10V
Group 19 Operation mode
19.11 Ext1/Ext2 selection
[0]EXT1, [1]EXT2, [3]DI1, [4]DI2, [5]DI3, [6]DI4, [7]DI5,
[32]Embeded fieldbus
19.17 Local control disable [0]No, [1]Yes
Group 20 Start/stop/direction
20.01 Ext1 commands [0]Not selected, [1]In1 Start, [2]In1 Start;In2 Dir, [3]In1 Start
fwd;In2 Start rev, [4]In1P Start;In2 Stop,[5]In1P Start;In2 Stop;In3
Dir, [6]In1P Start fwd;In2P Start rev;In3 Stop, [14]Embeded
fieldbus
20.03 Ext1 in1 source [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
20.04 Ext1 in2 source [0]Always off,[2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
20.05 Ext1 in3 source [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
Par. No. Par. Name Settings/Range (default value on bold)
