106 Parameters
20.06 Ext2 commands [0]Not selected, [1]In1 Start, [2]In1 Start;In2 Dir, [3]In1 Start
fwd;In2 Start rev, [4]In1P Start;In2 Stop,[5]In1P Start;In2 Stop;In3
Dir, [6]In1P Start fwd;In2P Start rev;In3 Stop, [14]Embeded
fieldbus
20.08 Ext2 in1 source [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
20.09 Ext2 in2 source [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
20.10 Ext2 in3 source [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
20.21 Direction [0]Request, [1]Forward, [2]Reverse
Group 21 Start/stop mode
21.01 Start mode [0]Fast, [1]Const time, [2]Automatic
21.02 Magnetization time 0 … 10000 ms, 500ms
21.03 Stop mode [0]Coast, [1]Ramp
21.19 Scalar start mode [0]Normal, [1]Const time, [2]Automatic, [3]Torque Boost,
[5]Flying start
Group 22 Speed reference selection
22.11 Ext1 speed ref1 [1]AI1 scaled, [2]AI2 scaled, [8]EFB ref1, [9]EFB ref2, [16]PID
22.18 Ext2 speed ref1 [0]Zero, [1]AI1 scaled, [2]AI2 scaled, [8]EFB ref1, [9]EFB ref2,
[16]PID
22.22 Constant speed sel1 [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
22.23 Constant speed sel2 [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
22.26 Constant speed 1 -30000.00 … 30000.00rpm, 300rpm
22.27 Constant speed 2 -30000.00 … 30000.00rpm, 600rpm
22.28 Constant speed 3 -30000.00 … 30000.00rpm, 900rpm
22.71 Motor potentiometer function [0]Disabled, [1]Enabled (init at stop/power-up), [2]Enabled
(resume always), [3]Enabled (init to actual)
22.72 Motor potentiometer initial
value
-32768.00… 32767.00, 0.00
22.73 Motor potentiometer up
source
[0]Not selected, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
22.74 Motor potentiometer down
source
[0]Not selected, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
22.75 Motor potentiometer ramp
time
0.0…3600.0 s, 40.0s
22.76
Motor potentiometer min
value
-32768.00… 32767.00, -50.00
22.77 Motor potentiometer max
value
-32768.00… 32767.00, 50.00
Group 23 Speed reference ramp
23.12 Acceleration time 1 0.000 … 1800.000s, 3.000s
23.13 Deceleration time 1 0.000 … 1800.000s, 3.000s
Group 28 Frequency reference chain
28.11 Ext1 frequency ref1 [1]AI1 scaled, [2]AI2 scaled, [8]EFB ref1, [9]EFB ref2, [16]PID
28.15 Ext2 frequency ref1 [0]Zero, [1]AI1 scaled, [2]AI2 scaled, [8]EFB ref1, [9]EFB ref2,
[16]PID
28.22 Constant frequency sel1 [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
Par. No. Par. Name Settings/Range (default value on bold)
