206 Parameters
31.02 External event 1 type Selects the type of external event 1. Fault
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.03 External event 2
source
Defines the source of external event 2. See also
parameter 31.04 External event 2 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.04 External event 2 type Selects the type of external event 2. Fault
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.05 External event 3
source
Defines the source of external event 3. See also
parameter 31.06 External event 3 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.06 External event 3 type Selects the type of external event 3.
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.07 External event 4
source
Defines the source of external event 4. See also
parameter 31.08 External event 4 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.08 External event 4 type Selects the type of external event 4.
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.09 External event 5
source
Defines the source of external event 5. See also
parameter 31.10 External event 5 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.10 External event 5 type Selects the type of external event 5. Fault
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.11 Fault reset selection Selects the source of an external fault reset signal. The
signal resets the drive after a fault trip if the cause of the
fault no longer exists.
0 -
>
1 = Reset
Note: A fault reset via FBA A and EFB MCW bit 7 is useful
when the start stop signal is through DIs (parameter 20.01
or 20.06) or from local control mode and the user wants a
fault reset through the fieldbus.
Whenever the remote control mode is in fieldbus (Start
stop command and reference is through fieldbus), the
fault can be reset from the fieldbus regardless of the
selection of the parameter.
Not used
Not used Not used 0
Not used Not used 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
No. Name/Value Description Default
FbEq 16
