Parameters 207
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status. 24
Supervision 2 Bit 1 of 32.01 Supervision status. 25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
EFB MCW bit 7 Control word bit 7 received through the embedded
fieldbus interface.
32
Other [bit] Source selection (see Terms and abbreviations). -
31.12 Autoreset selection Selects faults that are automatically reset. The parameter
is a 16-bit word with each bit corresponding to a fault type.
Whenever a bit is set to 1, the corresponding fault is
automatically reset.
The number and interval of reset attempts are defined by
parameters 31.14…31.16.
WARNING! Before you activate the function, make
sure that no dangerous situations can occur. The
function resets the drive automatically and
continues operation after a fault.
Notes:
• The autoreset function is only available in external
control; see section Local and external control locations
(page 44).
• Faults related to the Safe torque off (STO) function
cannot be automatically reset.
The bits of this binary number correspond to the following
faults:
0000h
0000h…FFFFh Automatic reset configuration word. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Fault
0 Overcurrent
1Overvoltage
2 Undervoltage
3 AI supervision fault
4…9 Reserved
10 Selectable fault (see parameter 31.13 Selectable fault)
11 External fault 1 (from source selected by parameter 31.01 External event 1 source)
12 External fault 2 (from source selected by parameter 31.03 External event 2 source)
13 External fault 3 (from source selected by parameter 31.05 External event 3 source)
14 External fault 4 (from source selected by parameter 31.07 External event 4 source)
15 External fault 5 (from source selected by parameter 31.09 External event 5 source)
