352 Fault tracing
2010 MOTOR TEMP
0308 bit 9
(programmable fault
function
3005…3009 / 3503)
Motor temperature is
too high (or appears to
be too high) due to
excessive load,
insufficient motor
power, inadequate
cooling or incorrect
start-up data.
For more information, see fault 0009
in Fault messages generated by the
drive on page 357.
Measured motor
temperature has
exceeded alarm limit
set by parameter 3503
ALARM LIMIT.
2011 UNDERLOAD
0308 bit 10
(programmable fault
function
3013…3015)
Motor load is too low
due to, eg, release
mechanism in driven
equipment.
Check for problem in driven
equipment.
Check fault function parameters.
Check motor power against drive
power.
2012 MOTOR STALL
0308 bit 11
(programmable fault
function
3010…3012)
Motor is operating in
stall region due to, eg,
excessive load or
insufficient motor
power.
Check motor load and drive ratings.
Check fault function parameters.
2013
1)
AUTORESET
0308 bit 12
Automatic reset alarm Check parameter group 31
AUTOMATIC RESET settings.
2018
1)
PID SLEEP
0309 bit 1
(programmable fault
function 1610)
Sleep function has
entered sleeping
mode.
See parameter groups 40 PROCESS
PID SET 1… 41 PROCESS PID SET
2.
2019 ID RUN
0309 bit 2
Motor Identification run
is on.
This alarm belongs to normal start-up
procedure. Wait until drive indicates
that motor identification is completed.
2021 START ENABLE 1
MISSING
0309 bit 4
No Start enable 1
signal received
Check parameter 1608 START
ENABLE 1 settings.
Check digital input connections.
Check fieldbus communication
settings.
2022 START ENABLE 2
MISSING
0309 bit 5
No Start enable 2
signal received
Check parameter 1609 START
ENABLE 2 settings.
Check digital input connections.
Check fieldbus communication
settings.
2023 EMERGENCY
STOP
0309 bit 6
Drive has received
emergency stop
command and ramps
to stop according to
ramp time defined by
parameter 2208
EMERG DEC TIME.
Check that it is safe to continue
operation.
Return emergency stop push button to
normal position.
CODE ALARM CAUSE WHAT TO DO
