104 Parameters
46 Monitoring/scaling settings Speed supervision settings; actual signal filtering; general scaling
settings.
256
47 Data storage Data storage parameters that can be written to and read from
using other parameters’ source and target settings.
258
49 Panel port communication Communication settings for the control panel port on the drive. 259
50 Fieldbus adapter (FBA) Fieldbus communication configuration. 261
51 FBA A settings Fieldbus adapter A configuration. 265
52 FBA A data in Selection of data to be transferred from drive to fieldbus controller
through fieldbus adapter A.
267
53 FBA A data out Selection of data to be transferred from fieldbus controller to drive
through fieldbus adapter A.
267
58 Embedded fieldbus Configuration of the embedded fieldbus (EFB) interface. 268
71 External PID1 Configuration of external PID. 286
76 Application features Application parameters for, e.g., Limit to limit control configuration. 288
90 Feedback selection Motor and load feedback configuration. 290
91 Encoder adapter settings
Configuration of encoder interface modules. 291
92 Encoder 1 configuration Settings for encoder 1. 291
95 HW configuration Various hardware-related settings. 292
96 System Language selection; access levels; macro selection; parameter
save and restore; control unit reboot; user parameter sets; unit
selection; user lock.
293
97 Motor control Switching frequency; slip gain; voltage reserve; flux braking; anti-
cogging (signal injection); IR compensation.
301
98 User motor parameters Motor values supplied by the user that are used in the motor
model.
304
99 Motor data Motor configuration settings. 305
Group Contents Page
