Control macros 47
Parameter default values for different macros
Chapter Parameters shows the default values of all parameters for the ABB standard
macro (factory macro). Some parameters have different default values for other
macros. The tables below lists the default values for those parameters for each
macro.
96.04 Macro select 1 =
ABB standard
12 =
Alternate
1 3 =
Motor potenti-
ometer
14 =
PID
10.24 RO1 source 15 = Fault (-1) 15 = Fault (-1) 15 = Fault (-1) 15 = Fault (-1)
12.20 AI1 scaled at AI1
max
50.0 50.0 50.0 50.0
13.12 AO1 source 2 = Output
frequency
2 = Output
frequency
2 = Output
frequency
2 = Output
frequency
13.18 AO1 source max 50.0 50.0 50.0 50.0
19.11 Ext1/Ext2
selection
0 = EXT1 0 = EXT1 0 = EXT1 0 = EXT1
20.01 Ext1 commands 2 = In1 Start;
In2 Dir
3 = In1 Start
fwd; In2 Start
2 = In1 Start;
In2 Dir
1 =In1 Start
20.03 Ext1 in1 2 = DI1 2 = DI1 2 = DI1 2 = DI1
20.04 Ext1 in2 3 = DI2 3 = DI2 3 = DI2 0 = Not
selected
20.05 Ext1 in3 0 = Not
selected
0 = Not
selected
0 = Not
selected
0 = Not
selected
20.06 Ext2 commands 0 = Not
selected
0 = Not
selected
0 = Not
selected
0 = Not
selected
20.08 Ext2 in1 0 = Not
selected
0 =
Not
selected
0 = Not
selected
0 = Not
selected
20.09 Ext2 in2 0 = Not
selected
0 = Not
selected
0 = Not
selected
0 = Not
selected
20.12 Run enable 1 1 = Selected 1 = Selected 1 = Selected 10 = DIO1
21.05 Emergency stop
source
1= Inactive
(true)
1= Inactive
(true)
1= Inactive
(true)
1= Inactive
(true)
22.11 Ext1 speed ref1 1 = AI1 scaled 1 = AI1 scaled 15 = Motor
potentiometer
16 = PID
22.18 Ext2 speed ref1 0 = Zero 0 = Zero 0 = Zero 0 = Zero
22.22 Constant speed
sel1
4 = DI3 4 = DI3 10 = DIO1 5 = DI4
22.23 Constant speed
sel2
5 = DI4 5 = DI4 0 = Not
selected
0 = Not
selected
