184 Parameters
26.73 Torque reference act 4 Displays the torque reference after application of
reference additive 1. See the control chain diagram on
page 453.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference after application of reference additive 1. See par.
46.03
26.74 Torque ref ramp out Displays the torque reference after limiting and ramping.
See the control chain diagram on page 453.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference after limiting and ramping. See par.
46.03
26.75 Torque reference act 5 Displays the torque reference after control mode
selection. See the control chain diagram on page 454.
This parameter is read-only.
-
-1600.0…1600.0% Torque reference after control mode selection. See par.
46.03
28
28 Frequency reference
chain
Settings for the frequency reference chain.
See the control chain diagrams on pages 453 and 454.
28.01 Frequency ref ramp
input
Displays the used frequency reference before ramping.
See the control chain diagram on page 453.
This parameter is read-only.
-
-500.00…500.00 Hz Frequency reference before ramping. See par.
46.02
28.02 Frequency ref ramp
output
Displays the final frequency reference (after selection,
limitation and ramping). See the control chain diagram on
page 453.
This parameter is read-only.
-
-500.00…500.00 Hz Final frequency reference. See par.
46.02
No. Name/Value Description Default
FbEq 16
