ABB ACS380 Series User Manual

244 Parameters
-32768.00… 32767.00
PID customer units
Process PID internal setpoint. 1 = 1 PID
customer
unit
40.91 Feedback data
storage
Storage parameter for receiving a process feedback value
eg. through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data.
Set the target selection parameter of that particular data
(58.101…58.114) to Feedback data storage. In 40.08 Set
1 feedback 1 source (or 40.09 Set 1 feedback 2 source),
select Feedback storage.
-
-327.68 … 327.67 Storage parameter for process feedback. 100 = 1
40.92 Setpoint data storage Storage parameter for receiving a process setpoint value
eg. through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data.
Set the target selection parameter of that particular data
(58.101…58.114) to Setpoint data storage. In 40.16 Set 1
setpoint 1 source (or 40.17 Set 1 setpoint 2 source),
select Setpoint data storage.
-
-327.68 … 327.67 Storage parameter for process setpoint. 100 = 1
41
41 Process PID set 2
A second set of parameter values for process PID control.
The selection between this set and first set (parameter
group 40 Process PID set 1) is made by parameter 40.57
PID set1/set2 selection.
See also parameters 40.01…40.06, and the control chain
diagrams on pages 456 and 457.
41.08 Set 2 feedback 1
source
See parameter 40.08 Set 1 feedback 1 source. AI2 percent
41.09 Set 2 feedback 2
source
See parameter 40.09 Set 1 feedback 2 source. Not selected
41.10 Set 2 feedback
function
See parameter 40.10 Set 1 feedback function. In1
41.11 Set 2 feedback filter
time
See parameter 40.11 Set 1 feedback filter time. 0.000 s
41.16 Set 2 setpoint 1
source
See parameter 40.16 Set 1 setpoint 1 source. AI1 percent
41.17 Set 2 setpoint 2
source
See parameter 40.17 Set 1 setpoint 2 source. Not selected
41.18 Set 2 setpoint function See parameter 40.18 Set 1 setpoint function. In1
41.19 Set 2 internal setpoint
sel1
See parameter 40.19 Set 1 internal setpoint sel1. Not selected
41.20 Set 2 internal setpoint
sel2
See parameter 40.20 Set 1 internal setpoint sel2. Not selected
41.21 Set 2 internal setpoint
1
See parameter 40.21 Set 1 internal setpoint 1. 0.00 PID
customer
units
41.22 Set 2 internal setpoint
2
See parameter 40.22 Set 1 internal setpoint 2. 0.00 PID
customer
units
No. Name/Value Description Default
FbEq 16
