ABB ACS380 Series - Page 237

Parameters 237
40.19 Set 1 internal setpoint
sel1
Selects together with 40.20 Set 1 internal setpoint sel2 the
internal setpoint out of the presets defined by parameters
40.21…40.23.
Note: Parameters 40.16 Set 1 setpoint 1 source and
40.17 Set 1 setpoint 2 source must be set to Internal
setpoint
Not selected
.
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Combined timer status.19
Timed function 3 Bit 2 of 34.01 Combined timer status.20
Supervision 1 Bit 0 of 32.01 Supervision status.21
Supervision 2 Bit 1 of 32.01 Supervision status.22
Supervision 3 Bit 2 of 32.01 Supervision status.23
Other [bit] Source selection (see Terms and abbreviations). -
40.20 Set 1 internal setpoint
sel2
Selects together with 40.19 Set 1 internal setpoint sel1 the
internal setpoint used out of the three internal setpoints
defined by parameters 40.21…40.23. See table at 40.19
Set 1 internal setpoint sel1.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02
DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status.20
No. Name/Value Description Default
FbEq 16
Source defined by
par. 40.19
Source defined by
par. 40.20
Internal setpoint active
0 0 Setpoint source
1 0 1 (par. 40.21)
0 1 2 (par. 40.22)
1 1 3 (par. 40.23)
