332 Additional parameter data
40 Process PID set 1
40.01 Process PID output actual Real -32768.00…32767.00 % 100 = 1%
40.02 Process PID feedback actual Real -32768.00…32767.00 PID
customer
units
100 = 1 PID
customer unit
40.03 Process PID setpoint actual Real -32768.00…32767.00 PID
customer
units
100 = 1 PID
customer unit
40.04 Process PID deviation actual Real -32768.00…32767.00 PID
customer
units
100 = 1 PID
customer unit
40.06 Process PID status word PB 0000h…FFFFh - 1 = 1
40.07 Process PID operation mode List 0…2 - 1 = 1
40.08 Set 1 feedback 1 source Analog src --1 = 1
40.09 Set 1 feedback 2 source Analog src --1 = 1
40.10 Set 1 feedback function List 0…11 - 1 = 1
40.11 Set 1 feedback filter time Real 0.000…30.000 s 1000 = 1 s
40.16 Set 1 setpoint 1 source Analog src --1 = 1
40.17 Set 1 setpoint 2 source Analog src --1 = 1
40.18 Set 1 setpoint function List 0…11 - 1 = 1
40.19 Set 1 internal setpoint sel1 Binary src --1 = 1
40.20 Set 1 internal setpoint sel2 Binary src --1 = 1
40.21 Set 1 internal setpoint 1 Real -32768.00…32767.00 PID
customer
units
100 = 1 PID
customer unit
40.22 Set 1 internal setpoint 2 Real -32768.00…32767.00 PID
customer
units
100 = 1 PID
customer unit
40.23 Set 1 internal setpoint 3 Real -32768.00…32767.00 PID
customer
units
100 = 1 PID
customer unit
40.26 Set 1 setpoint min Real -32768.00…32767.00 - 100 = 1
40.27 Set 1 setpoint max Real -32768.00…32767.00 - 100 = 1
40.28 Set 1 setpoint increase time Real 0.0…1800.0 s 10 = 1 s
40.29 Set 1 setpoint decrease time Real 0.0…1800.0 s 10 = 1 s
40.30 Set 1 setpoint freeze enable Binary src --1 = 1
40.31 Set 1 deviation inversion Binary src --1 = 1
40.32 Set 1 gain Real 0.10…100.00 - 100 = 1
40.33 Set 1 integration time Real 0.0…9999.0 s 10 = 1 s
40.34 Set 1 derivation time Real 0.000…10.000 s 1000 = 1 s
40.35 Set 1 derivation filter time Real 0.0…10.0 s 10 = 1 s
40.36 Set 1 output min Real -32768.0…32767.0 - 10 = 1
40.37 Set 1 output max Real -32768.0…32767.0 - 10 = 1
40.38 Set 1 output freeze enable Binary src --1 = 1
40.43 Set 1 sleep level Real 0.0…32767.0 - 10 = 1
No. Name Type Range Unit FbEq32
