Additional parameter data 333
40.44 Set 1 sleep delay Real 0.0…3600.0 s 10 = 1 s
40.45 Set 1 sleep boost time Real 0.0…3600.0 s 10 = 1 s
40.46 Set 1 sleep boost step Real 0.0…32767.0 PID
customer
units
100 = 1 PID
customer unit
40.47 Set 1 wake-up deviation Real -32768.00 … 32767.00 PID
customer
units
100 = 1 PID
customer unit
40.48 Set 1 wake-up delay Real 0.00…60.00 s 100 = 1 s
40.49 Set 1 tracking mode Binary src --1 = 1
40.50 Set 1 tracking ref selection Analog src --1 = 1
40.57 PID set1/set2 selection Binary src --1 = 1
40.58 Set 1 increase prevention List 0…3 - 1 = 1
40.59 Set 1 decrease prevention List 0…3 - 1 = 1
40.62 PID internal setpoint actual Real -32768.00…32767.00 PID
customer
units
100 = 1 PID
customer unit
40.91 Feedback data storage Real -327.68 … 327.67 - 100 = 1
40.92 Setpoint data storage Real -327.68 … 327.67 - 100 = 1
41 Process PID set 2
41.08 Set 2 feedback 1 source Analog src --1 = 1
41.09 Set 2 feedback 2 source Analog src --1 = 1
41.10 Set 2 feedback function List 0…11 - 1 = 1
41.11 Set 2 feedback filter time Real 0.000…30.000 s 1000 = 1 s
41.16 Set 2 setpoint 1 source Analog src --1 = 1
41.17 Set 2 setpoint 2 source Analog src --1 = 1
41.18 Set 2 setpoint function List 0…11 - 1 = 1
41.19 Set 2 internal setpoint sel1 Binary src --1 = 1
41.20 Set 2 internal setpoint sel2 Binary src --1 = 1
41.21 Set 2 internal setpoint 1 Real -32768.0…32767.0 PID
customer
units
100 = 1 PID
customer unit
41.22 Set 2 internal setpoint 2 Real -32768.0…32767.0 PID
customer
units
100 = 1 PID
customer unit
41.23 Set 2 internal setpoint 3 Real -32768.0…32767.0 PID
customer
units
100 = 1 PID
customer unit
41.26 Set 2 setpoint min Real -32768.0…32767.0 - 100 = 1
41.27 Set 2 setpoint max Real -32768.0…32767.0 - 100 = 1
41.28 Set 2 setpoint increase time Real 0.0…1800.0 s 10 = 1 s
41.29 Set 2 setpoint decrease time Real 0.0…1800.0 s 10 = 1 s
41.30 Set 2 setpoint freeze enable Binary src --1 = 1
41.31 Set 2 deviation inversion Binary src --1 = 1
41.32 Set 2 gain Real 0.10…100.00 - 100 = 1
No. Name Type Range Unit FbEq32
