334 Additional parameter data
41.33 Set 2 integration time Real 0.0…9999.0 s 10 = 1 s
41.34 Set 2 derivation time Real 0.000…10.000 s 1000 = 1 s
41.35 Set 2 derivation filter time Real 0.0…10.0 s 10 = 1 s
41.36 Set 2 output min Real -32768.0…32767.0 - 10 = 1
41.37 Set 2 output max Real -32768.0…32767.0 - 10 = 1
41.38 Set 2 output freeze enable Binary src --1 = 1
41.43 Set 2 sleep level Real 0.0…32767.0 - 10 = 1
41.44 Set 2 sleep delay Real 0.0…3600.0 s 10 = 1 s
41.45 Set 2 sleep boost time Real 0.0…3600.0 s 10 = 1 s
41.46 Set 2 sleep boost step Real 0.0…32767.0 PID
customer
units
100 = 1 PID
customer unit
41.47 Set 2 wake-up deviation Real -2147483648…
2147483647
PID
customer
units
100 = 1 PID
customer unit
41.48 Set 2 wake-up delay Real 0.00…60.00 s 100 = 1 s
41.49 Set 2 tracking mode Binary src --1 = 1
41.50 Set 2 tracking ref selection Analog src --1 = 1
41.58 Set 2 increase prevention List 0…3 - 1 = 1
41.59 Set 2 decrease prevention List 0…3 - 1 = 1
43 Brake chopper
43.01 Braking resistor temperature Real 0.0…120.0 % 10 = 1%
43.06 Brake chopper enable List 0…2 - 1 = 1
43.07 Brake chopper runtime
enable
Binary src --1 = 1
43.08 Brake resistor thermal tc Real 0…10000 s 1 = 1 s
43.09 Brake resistor Pmax cont Real 0.00…10000.00 kW 100 = 1 kW
43.10 Brake resistance Real 0.0…1000.0 ohm 10 = 1 ohm
43.11 Brake resistor fault limit Real 0…150 % 1 = 1%
43.12 Brake resistor warning limit Real 0…150 % 1 = 1%
44 Mechanical brake control
44.01 Brake control status PB 0000h…FFFFh - 1 = 1
44.02 Brake torque memory Real -1600.0...1600.0 % 10 = 1%
44.03 Brake open torque reference Real -1600.0...1600.0 % 10 = 1%
44.06 Brake control enable Binary src --1 = 1
44.07 Brake acknowledge selection Binary src --1 = 1
44.08 Brake open delay Real 0.00…5.00 s 100 = 1 s
44.09 Brake open torque source Analog src --1 = 1
44.10 Brake open torque Real -1000...1000 % 10 = 1%
44.11 Keep brake closed Binary src --1 = 1
44.12 Brake close request Binary src --1 = 1
44.13 Brake close delay Real 0.00…60.00 s 100 = 1 s
44.14 Brake close level Real 0.0…1000.0 rpm 100 = 1 rpm
No. Name Type Range Unit FbEq32
