Start-up, ID run and use 23
3
Start-up, ID run and use
Contents
• Start up the drive
• Do the identification (ID) run
• Start and stop the drive
• Change the rotation direction
• Set the speed or frequency reference
• Set the drive parameters
• Open Diagnostics
• Change the units
Start up the drive
1. Select the unit (international or US) and press OK.
The drive recognizes the connected adapter and sets the correct settings. This
may take a few seconds depending on the adapter.
2. In the Motor data view, set the motor type:
AsynM: Asynchronous motor
PMSM: Permanent magnet motor, or
SynRM: Synchronous reluctance motor
3. Set the motor control mode:
Vector: Speed reference. This is suitable for most cases. The drive does an
automatic stand-still ID run.
Scalar: Frequency reference.
Use this mode when:
- The number of motors can change.
