Parameters 219
On 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Other [bit] Source selection (see Terms and abbreviations). -
34.112 Boost time duration Defines the time inside which the boost time is
deactivated after boost time activation signal is switched
off.
Example: If parameter 34.111 Boost time activation
source source is set to DI1 and 34.112 is set to 00 01:30,
the boost time is active for 1 hour and 30 minutes after
digital input DI is deactivated.
00 00:00
00 00:00…00 00:00 Boost time duration. 1 = 1
35
35 Motor thermal
protection
Motor thermal protection settings such as temperature
measurement configuration, load curve definition and
motor fan control configuration.
See also section Motor thermal protection (page 92).
35.01 Motor estimated
temperature
Displays the motor temperature as estimated by the
internal motor thermal protection model (see parameters
35.50…35.55). The unit is selected by parameter 96.16
Unit selection.
This parameter is read-only.
-
-60…1000 °C or
-76…1832 °F
Estimated motor temperature. 1 = 1°
35.02 Measured temperature
1
Displays the temperature received through the source
defined by parameter 35.11 Temperature 1 source. The
unit is selected by parameter 96.16 Unit selection.
Note: With a PTC sensor, either 0 ohm (normal
temperature) or the value of parameter 35.12
Temperature 1 fault limit (excessive temperature) is
shown.
This parameter is read-only.
-
-10…1000 °C or
14…1832 °F, 0 ohm or
[35.12] ohm
Measured temperature 1. 1 = 1 unit
35.03 Measured temperature
2
Displays the temperature received through the source
defined by parameter 35.21 Temperature 2 source. The
unit is selected by parameter 96.16 Unit selection.
Note: With a PTC sensor, either 0 ohm (normal
temperature) or the value of parameter 35.22
Temperature 2 fault limit (excessive temperature) is
shown.
This parameter is read-only.
-
-10…1000 °C or
14…1832 °F, 0 ohm or
[35.22] ohm
Measured temperature 2. 1 = 1 unit
No. Name/Value Description Default
FbEq 16
