Additional parameter data 313
7
Additional parameter data
Contents
• Terms and abbreviations
• Fieldbus addresses
• Parameter groups 1…9
• Parameter groups 10…99
Terms and abbreviations
Term Definition
Actual signal Signal measured or calculated by the drive. Usually can only be monitored
but not adjusted; some counter-type signals can however be reset.
Analog src Analog source: the parameter can be set to the value of another parameter
by choosing “Other”, and selecting the source parameter from a list.
In addition to the “Other” selection, the parameter may offer other pre-
selected settings.
Binary src Binary source: the value of the parameter can be taken from a specific bit
in another parameter value (“Other”). Sometimes the value can be fixed to
0 (false) or 1 (true). In addition, the parameter may offer other pre-selected
settings.
Data Data parameter.
FbEq32 32-bit fieldbus equivalent: The scaling between the value shown on the
panel and the integer used in communication when a 32-bit value is
selected for transmission to an external system.
The corresponding 16-bit scalings are listed in chapter Parameters.
