Parameters 131
12.30 AI2 scaled at AI2 max Defines the real value that corresponds to the minimum
analog input AI2 value defined by parameter 12.28 AI2
max. See the drawing at parameter of 12.29 AI2 scaled at
AI2 min
50.000
-32768.000…
32767.000
Real value corresponding to maximum AI2 value. 1 = 1
12.101 AI1 percent value Value of analog input AI1 in percent of AI1 scaling (12.18
AI1 max - 12.17 AI1 min).
-
0.00… 100.00 AI1 value 100 = 1%
12.102 AI2 percent value Value of analog input AI2 in percent of AI1 scaling (12.28
AI2 max - 12.27 AI2 min).
-
0.00… 100.00 AI2 value 100 = 1%
13
13 Standard AO
Configuration of standard analog outputs.
13.02 AO force selection Selects the analog outputs that will be forced to values
defined by parameters.
The true source signals of the analog outputs can be
overridden for eg. testing purposes. A forced value
parameter is provided for each analog output, and its
value is applied whenever the corresponding bit in this
parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 13.02 and 13.11).
0000h
0000h…FFFFh Forced values selector for analog output AO1. 1 = 1
13.11 AO1 actual value Displays the value of AO1 in mA.
This parameter is read-only.
-
0.000…22.000 mA Value of AO1. 1 = 1 mA
13.12 AO1 source Selects a signal to be connected to analog output AO1. Output
frequency
Zero None. 0
Motor speed used 01.01 Motor speed used 1
Output frequency 01.06 Output frequency 3
Motor current 01.07 Motor current 4
Motor current % of
motor nom
01.08 Motor current % of motor nom 5
Motor torque 01.10 Motor torque 6
DC voltage 01.11 DC voltage 7
Output power 01.14 Output power 8
Speed ref ramp in 23.01 Speed ref ramp input.10
Speed ref ramp out 23.02 Speed ref ramp output 11
Speed ref used 24.01 Used speed reference 12
Freq ref used 28.02 Frequency ref ramp output 14
No. Name/Value Description Default
FbEq 16
Bit Value
0 1 = Force AO1 to value of parameter 13.13 AO1 forced value.
2…15 Reserved
