320 Additional parameter data
12.28 AI2 max Real 4.000…20.000 mA or
0.000…10.000 V
mA or V 1000 = 1 unit
12.29 AI2 scaled at AI2 min Real -32768.000…32767.000 - 1000 = 1
12.30 AI2 scaled at AI2 max Real -32768.000…32767.000 - 1000 = 1
12.101 AI1 percent value Real 0.00…100.00 % 100 = 1%
12.102 AI2 percent value Real 0.00…100.00 % 100 = 1%
13 Standard AO
13.02 AO force selection PB 0000h…FFFFh - 1 = 1
13.11 AO1 actual value Real 0.000…22.000 mA 1000 = 1 mA
13.12 AO1 source Analog src --1 = 1
13.13 AO1 forced value Real 0.000…22.000 mA 1000 = 1 mA
13.15 AO1 unit selection List 2, 10 - 1 = 1
13.16 AO1 filter time Real 0.000…30.000 s 1000 = 1 s
13.17 AO1 source min Real -32768.0…32767.0 - 10 = 1
13.18 AO1 source max Real -32768.0…32767.0 - 10 = 1
13.19 AO1 out at AO1 src min Real 0.000…22.000 mA 1000 = 1 mA
13.20 AO1 out at AO1 src max Real 0.000…22.000 mA 1000 = 1 mA
13.91 AO1 data storage Real -327.68 … 327.67 - 100 = 1
15 I/O extension module
15.01 Extension module type List 0…3 - 1 = 1
15.02 Detected extension module List 0…3 - 1 = 1
15.04 RO/DO status PB 0000h…FFFFh - 1 = 1
15.05 RO/DO force selection PB 0000h…FFFFh - 1 = 1
15.06 RO/DO forced data PB 0000h…FFFFh - 1 = 1
15.07 RO2 source Binary src --1 = 1
15.08 RO2 ON delay Real 0.0…3000.0 s 10 = 1 s
15.09 RO2 OFF delay Real 0.0…3000.0 s 10 = 1 s
15.10 RO3 source Binary src --1 = 1
15.11 RO3 ON delay Real 0.0…3000.0 s 10 = 1 s
15.12 RO3 OFF delay Real 0.0…3000.0 s 10 = 1 s
15.13 RO4 source Binary src --1 = 1
15.14 RO4 ON delay Real 0.0…3000.0 s 10 = 1 s
15.15 RO4 OFF delay Real 0.0…3000.0 s 10 = 1 s
15.16 RO5 source Binary src --1 = 1
15.17 RO5 ON delay Real 0.0…3000.0 s 10 = 1 s
15.18 RO5 OFF delay Real 0.0…3000.0 s 10 = 1 s
19 Operation mode
19.01 Actual operation mode List 1…6, 10…20 - 1 = 1
19.11 Ext1/Ext2 selection Binary src --1 = 1
19.12 Ext1 control mode List 1…5 - 1 = 1
19.14 Ext2 control mode List 1…5 - 1 = 1
No. Name Type Range Unit FbEq32
