Additional parameter data 321
19.16 Local control mode List 0…1 - 1 = 1
19.17 Local control disable List 0…1 - 1 = 1
20 Start/stop/direction
20.01 Ext1 commands List 0…6, 11…12, 14 - 1 = 1
20.02 Ext1 start trigger type List 0…1 - 1 = 1
20.03 Ext1 in1 Binary src --1 = 1
20.04 Ext1 in2 Binary src --1 = 1
20.05 Ext1 in3 Binary src --1 = 1
20.06 Ext2 commands List 0…6, 11…12, 14 - 1 = 1
20.07 Ext2 start trigger type List 0…1 - 1 = 1
20.08 Ext2 in1 Binary src --1 = 1
20.09 Ext2 in2 Binary src --1 = 1
20.10 Ext2 in3 Binary src --1 = 1
20.11 Run enable stop mode List 0…2 - 1 = 1
20.12 Run enable 1 Binary src --1 = 1
20.13 Run enable 2 Binary src --1 = 1
20.14 Run enable 3 Binary src --1 = 1
20.15 Run enable 4 Binary src --1 = 1
20.19 Enable start signal Binary src --1 = 1
20.21 Direction List 0…2 - 1 = 1
20.22 Enable to rotate Binary src --1 = 1
20.25 Jog enable Binary src --1 = 1
20.26 Jog 1 start Binary src --1 = 1
20.27 Jog 2 start Binary src --1 = 1
21 Start/stop mode
21.01 Vector start mode List 0…2 - 1 = 1
21.02 Magnetization time Real 0…10000 ms 1 = 1 ms
21.03 Stop mode List 0…2 - 1 = 1
21.04 Emergency stop mode List 0…3 - 1 = 1
21.05 Emergency stop source Binary src --1 = 1
21.06 Zero speed limit Real 0.00…30000.00 rpm 100 = 1 rpm
21.07 Zero speed delay Real 0…30000 ms 1 = 1 ms
21.08 DC current control PB 00b…11b - 1 = 1
21.09 DC hold speed Real 0.00…1000.00 rpm 100 = 1 rpm
21.10 DC current reference Real 0.0…100.0 % 10 = 1%
21.11 Post magnetization time Real 0…3000 s 1 = 1 s
21.14 Pre-heating input source Binary src --1 = 1
21.16 Pre-heating current Real 0.0…30.0 % 10 = 1%
21.18 Auto restart time Real 0.0, 0.1 … 10.0 s 10 = 1 s
21.19 Scalar start mode List 0…2 - 1 = 1
21.21 DC hold frequency Real 0.00…1000.00 Hz 100 = 1 Hz
No. Name Type Range Unit FbEq32
