Parameters 267
51.32 FBA A comm SW ver Displays the common program revision of the adapter
module in format axyz, where a = major revision number,
xy = minor revision number, z = correction number or
letter.
Example: 190A = revision 1.90A.
Common program revision of adapter module. -
51.33 FBA A appl SW ver Displays the application program revision of the adapter
module in format axyz, where a = major revision number,
xy = minor revision number, z = correction number or
letter.
Example: 190A = revision 1.90A.
Application program version of adapter module. -
52
52 FBA A data in
Selection of data to be transferred from drive to fieldbus
controller through fieldbus adapter A.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter,
the next parameter is automatically reserved.
52.01 FBA A data in1 Parameters 52.01…52.12 select data to be transferred
from the drive to the fieldbus controller through fieldbus
adapter A.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
SW 16bit Status Word (16 bits) 4
Act1 16bit Actual value ACT1 (16 bits) 5
Act2 16bit Actual value ACT2 (16 bits) 6
CW 32bit Control Word (32 bits) 11
Ref1 32bit Reference REF1 (32 bits) 12
Ref2 32bit Reference REF2 (32 bits) 13
SW 32bit Status Word (32 bits) 14
Act1 32bit Actual value ACT1 (32 bits) 15
Act2 32bit Actual value ACT2 (32 bits) 16
SW2 16bit Status Word 2 (16 bits) 24
Other Source selection (see Terms and abbreviations). -
…… … …
52.12 FBA A data in12 See parameter 52.01 FBA A data in1. None
53
53 FBA A data out
Selection of data to be transferred from fieldbus controller
to drive through fieldbus adapter A.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter,
the next parameter is automatically reserved.
53.01 FBA A data out1 Parameters 53.01…53.12 select data to be transferred
from the fieldbus controller to the drive through fieldbus
adapter A.
None
None None. 0
No. Name/Value Description Default
FbEq 16
