Terms and abbreviations
Term/abbreviation Explanation
ACS-AP-x Assistant control panel, advanced operator keypad for
communication with the drive
ACS-BP-S Basic control panel
AI Analog input; interface for analog input signals
AO Analog output; interface for analog output signals
AsynM Asynchronous motor
BAPO-01 Optional side-mounted auxiliary power extension module
BCAN-11 CANopen interface.
BCBL-01 Optional USB to RJ45 cable
BMIO-01 I/O and Modbus module
Brake chopper Conducts the surplus energy from the intermediate circuit of the
drive to the brake resistor when necessary. The chopper
operates when the DC link voltage exceeds a certain maximum
limit. The voltage rise is typically caused by deceleration
(braking) of a high inertia motor.
Brake resistor Dissipates the drive surplus braking energy conducted by the
brake chopper to heat. Essential part of the brake circuit. See
chapter Resistor breaking in the hardware manual of the drive.
BREL-01 Optional side-mounted relay output extension module
BTAC-02 Optional side-mounted pulse encoder interface module
Capacitor bank See DC link capacitors.
CCA-01 Optional cold configuration adapter
Control board Circuit board in which the control program runs
DC link DC circuit between rectifier and inverter
DC link capacitors Energy storage which stabilizes the intermediate circuit DC
voltage
DI Digital input; interface for digital input signals
DO Digital output; interface for digital output signals
Drive Frequency converter for controlling AC motors
EFB Embedded fieldbus
FBA Fieldbus adapter
FCAN-01 / -01-M Optional CANopen adapter module
FCNA-01 Optional ControlNet adapter module
FDNA-01 Optional DeviceNet adapter module
FECA-01/-01-M Optional EtherCAT adapter module
FENA-11/-21/-21-M Optional Ethernet adapter module for EtherNet/IP, Modbus TCP
and PROFINET IO protocols
FEPL-02 Ethernet POWERLINK adapter module
FPBA-01/-01-M Optional PROFIBUS DP adapter module
