288 Parameters
0.0…32767.0 Range 1 = 1
71.40 Deadband delay Defines the deadband delay for the deadband function.
See parameter 71.39 Deadband range.
0.0 s
0.0…3600.0 s Delay 1 = 1 s
71.58 Increase prevention See parameter 40.58 Set 1 increase prevention. No
71.59 Decrease prevention See parameter 40.59 Set 1 decrease prevention. No
71.62 Internal setpoint actual See parameter 40.62 PID internal setpoint actual. -
76
76 Application features
Application parameters for eg., Limit to limit control
configuration.
76.01 Limit to limit control
status
Displays the state of the limited to limit control state
machine.
Not
initialized
0...5 1 = 1
76.02 Limit to limit enable The Limit to limit control enable selection parameter. Not selected
Not selected 0 0
Selected 1 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0) 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1) 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2) 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3) 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0) 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Timed function 1 Bit 0 of 34.01 Timed functions status 18
Timed function 2 Bit 1 of 34.01 Timed functions status 19
Timed function 3 Bit 2 of 34.01 Timed functions status 20
Supervision 1 Bit 0 of 32.01 Supervision status 24
Supervision 2 Bit 1 of 32.01 Supervision status 25
Supervision 3 Bit 2 of 32.01 Supervision status 26
Supervision 4 Bit 3 of 32.01 Supervision status 27
Supervision 5 Bit 4 of 32.01 Supervision status 28
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Not initialized The initial value of the state machine.
1 Rev zero, Fwd
max speed
The reverse speed is limited to zero speed, and the forward direction
speed is not limited by Limit to limit control.
2 Rev safe, Fwd
max speed
The reverse speed is limited to safe speed, and the forward direction
speed is not limited by Limit to limit control.
3 Rev max, Fwd
max speed
The reverse speed is not limited, and the forward direction speed is
not limited by Limit to limit control.
4 Rev max, Fwd
safe speed
The reverse speed is not limited, and the forward direction speed is
limited to safe speed by Limit to limit control.
5 Rev max, Fwd
zero speed
The reverse speed is not limited, and the forward direction speed is
limited to zero speed by Limit to limit control.
6...15 Reserved
