Parameters 243
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status.20
Supervision 1 Bit 0 of 32.01 Supervision status 21
Supervision 2 Bit 1 of 32.01 Supervision status 22
Supervision 3 Bit 2 of 32.01 Supervision status.23
Supervision 4 N/A 24
Supervision 5 N/A 25
Supervision 6 N/A 26
Other [bit] Source selection (see Terms and abbreviations). -
40.58 Set 1 increase
prevention
Prevention of PID integration term increase for PID set 1. No
No Increase prevention not in use. 0
Limiting The PID integration term is not increased if the maximum
value for the PID output is reached. This parameter is
valid for the PID set 1.
1
Ext PID min lim The process PID integration term is not increased when
the output of the external PID has reached it's minimum
limit. In this setup, the external PID is used as a source for
the process PID. This parameter is valid for the PID set 1.
2
Ext PID max lim The process PID integration term is not increased when
the output of the external PID has reached it's maximum
limit. In this setup, the external PID is used as a source for
the process PID. This parameter is valid for the PID set 1.
3
40.59 Set 1 decrease
prevention
Prevention of PID integration term decrease for PID set 1. No
No Decrease prevention not in use. 0
Limiting The PID integration term is not decreased if the minimum
value for the PID output is reached. This parameter is
valid for the PID set 1.
1
Ext PID min lim The process PID integration term is not decreased when
the output of the external PID has reached it's minimum
limit. In this setup, the external PID is used as a source for
the process PID. This parameter is valid for the PID set 1.
2
Ext PID max lim The process PID integration term is not decreased when
the output of the external PID has reached it's maximum
limit. In this setup, the external PID is used as a source for
the process PID. This parameter is valid for the PID set 1.
3
40.62 PID internal setpoint
actual
Displays the value of the internal setpoint. See the control
chain diagram on page 456.
This parameter is read-only.
-
No. Name/Value Description Default
FbEq 16
