242 Parameters
40.48 Set 1 wake-up delay Defines a wake-up delay for the sleep function to prevent
nuisance wake-ups. See parameter 40.47 Set 1 wake-up
deviation.
The delay timer starts when the deviation exceeds the
wake-up level (40.47 Set 1 wake-up deviation), and resets
if the deviation falls below the wake-up level.
0.50 s
0.00…60.00 s Wake-up delay. 1 = 1 s
40.49 Set 1 tracking mode Activates (or selects a source that activates) tracking
mode. In tracking mode, the value selected by parameter
40.50 Set 1 tracking ref selection is substituted for the PID
controller output. See also section Tracking (page 78).
1 = Tracking mode enabled
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status.20
Supervision 1 Bit 0 of 32.01 Supervision status.21
Supervision 2 Bit 1 of 32.01 Supervision status.22
Supervision 3 Bit 2 of 32.01 Supervision status.23
Supervision 4 Bit 3 of 32.01 Supervision status 24
Supervision 5 Bit 4 of 32.01 Supervision status 25
Supervision 6 Bit 5 of 32.01 Supervision status 26
Other [bit] Source selection (see Terms and abbreviations). -
40.50 Set 1 tracking ref
selection
Selects the value source for tracking mode. See
parameter 40.49 Set 1 tracking mode.
Not selected
Not selected None. 0
AI1 scaled 12.12 AI1 scaled value 1
AI2 scaled 12.22 AI2 scaled value.2
FB A ref1 03.05 FB A reference 1 3
FB A ref2 03.06 FB A reference 2 4
Other Source selection (see Terms and abbreviations). -
40.57 PID set1/set2
selection
Selects the source that determines whether process PID
parameter set 1 (parameters 40.07…40.50) or set 2
(group 41 Process PID set 2) is used.
0 = PID set 1 in use
1 = PID set 2 in use
Not selected
Not selected 0. 0
Selected 1. 1
No. Name/Value Description Default
FbEq 16
