Parameters 241
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Timed function 1 Bit 0 of 34.01 Timed functions status.18
Timed function 2 Bit 1 of 34.01 Timed functions status.19
Timed function 3 Bit 2 of 34.01 Timed functions status... 20
Supervision 1 Bit 0 of 32.01 Supervision status 21
Supervision 2 Bit 1 of 32.01 Supervision status 22
Supervision 3 Bit 2 of 32.01 Supervision status.23
Other [bit] Source selection (see Terms and abbreviations). -
40.43 Set 1 sleep level Defines the start limit for the sleep function. If the value is
0.0, set 1 sleep mode is disabled.
The sleep function compares the motor speed to the value
of this parameter. If the motor speed remains below this
value longer than the sleep delay defined by 40.44 Set 1
sleep delay, the drive enters the sleep mode and stops the
motor.
0.0
0.0…32767.0 Sleep start level. 1 = 1
40.44 Set 1 sleep delay Defines a delay before the sleep function actually
becomes enabled, to prevent nuisance sleeping.
The delay timer starts when the sleep mode is enabled by
parameter 40.43 Set 1 sleep level, and resets when the
sleep mode is disabled.
60.0 s
0.0…3600.0 s Sleep start delay. 1 = 1 s
40.45 Set 1 sleep boost time Defines a boost time for the sleep boost step. See
parameter 40.46 Set 1 sleep boost step.
0.0 s
0.0…3600.0 s Sleep boost time. 1 = 1 s
40.46 Set 1 sleep boost step When the drive is entering sleep mode, the process
setpoint is increased by this value for the time defined by
parameter 40.45 Set 1 sleep boost time.
If active, sleep boost is aborted when the drive wakes up.
0.0 PID
customer
units
0.0…32767.0 PID
customer units
Sleep boost step. 1 = 1 PID
customer
unit
40.47 Set 1 wake-up
deviation
Defines the wake-up level as deviation between process
setpoint and feedback.
When the deviation exceeds the value of this parameter,
and remains there for the duration of the wake-up delay
(40.48
Set 1 wake-up delay), the drive wakes up.
See also parameter 40.31 Set 1 deviation inversion.
0.00 PID
customer
units
-32768.00 …
32767.00 PID
customer units
Wake-up level (as deviation between process setpoint
and feedback).
1 = 1 PID
customer
unit
No. Name/Value Description Default
FbEq 16
